Home > Products > TY Turbine Oil Purifier > Turbine Hydraulic Oil Renewal machine
Turbine Hydraulic Oil Renewal machine
- 82 Set / Sets per Month
- Shanghai Chongqing etc.
- T/T
Product Details
Place of Origin: | Chongqing, China | Brand Name: | CTBU | Model Number: | TY |
Packaging Details
wooden case
Product Description
Specifications
remove water, impurities, saponificated materials,acid, flue and so on from tubrine oil;vacuum on line processing
SGS, CE.
Detailed Product Description
TY series oil purifier specially for turbine oil use the technologies, such as, contrifugation, expansion, condension, molecular adsorption, vacuum dry, mechanical filter, fuzzy control and so on.
Main Features:
1. Use patented technology to produce.such as high-efficitive separating tower, fuzzy control technology, dewatering and degassing very effectively.
2. It can purify the losing-efficient insulation oil and make the oil reach the new oil standard without power cut, changing the oil or using filtering papers.
3. Have the function of filling oil under vacuum condition.
4. Solve the problem of removing the acetylene
5. The purifier has large route, strong capability of holding dirt and can be used for a long time.
6. This machine is small, light weight and convenient.
7. The ultrasonic cleaning function can be selected
8.Have the multi-functions ofcontrifugal separation, molecular filter,condension de-watering and vacuum dry.
9.Have the functions of automatic burning protection and eliminating foam.
10.Operate steadly and the noise is specially low.
Advantages:
The machines can remove the water, impurities, saponificated materials,acid, flue,colority to make the emulsified turbine oil demulsified and transparent and reach the qualified standard. These machines are used in hydraulic power,thermal power plants and turbogenerators to purify the oils on line.
product name | model | Main technical parameters | oil pipe (mm) | voltage (V) | total power (kw) | LXWXH (cm) | weight (kg) | ||||||
flow (L/h) | working pressure (MPa) | working vacuum(MPa) | particle count(NAS1638) | water content (μ/) | acid number(mgKOH/g) | appearance | |||||||
Oil Purifier Specially for Turbine Oil | TY-1000 | 1000 | ≤0.5 | 0.097 | 5/6 | ≤50 | 0.03 | Transparent | 25 | 220/380/ 415/3
| 16.19 | 160x105x160 | 700 |
TY-2000 | 2000 | ≤0.5 | 0.097 | 5/6 | ≤50 | 0.03 | Transparent | 32 | 19.94 | 160x110x165 | 780 | ||
TY-4000 | 4000 | ≤0.5 | 0.097 | 5/6 | ≤50 | 0.03 | Transparent | 38 | 26.29 | 180x120x178 | 960 | ||
TY-6000 | 6000 | ≤0.5 | 0.097 | 5/6 | ≤50 | 0.03 | Transparent | 38 | 39.09 | 190x130x188 | 1000 | ||
TY-8000 | 8000 | ≤0.5 | 0.097 | 5/6 | ≤50 | 0.03 | Transparent | 50 | 53.29 | 190x130x180 | 1100 | ||
TY-10000 | 10000 | ≤0.5 | 0.097 | 5/6 | ≤50 | 0.03 | Transparent | 50 | 54.09 | 200x143x193 | 1200 | ||
TY-12000 | 12000 | ≤0.5 | 0.097 | 5/6 | ≤50 | 0.03 | Transparent | 50 | 56.59 | 200x143x193 | 1300 | ||
TY-16000 | 16000 | ≤0.5 | 0.097 | 5/6 | ≤50 | 0.03 | Transparent | 64 | 70.0 | 210x145x200 | 1550 |
Company Profile
I-Brief introduction:
1.1-Type: CTBU China, which is one University based and State-Owned Government company since from the year 1990 (at the beginning of year 1980, we're one R&D center of our own University). Ltd. Our Main business is Manufacture and Service area.
1.2-Legal representative: Professor Zhang, who is the vice-director of the National Separating Mechanism Standardization Technical Committees in China.
1.3-Certificates & Awards: We have acquired a lot of patented technique certificates:
1.3.1-Eureka International Invention Prize Award;
1.3.2-"Technical Star" awarded by the UN;
1.3.3-CE certificate to enter European market;
1.3.4-ISO9001 International Certificate;
1.3.5-TC92 Certificate;
1.3.6-Other awards from China Electricity Bureau, LPA(Liberation of People's Army) Medical Service Bureau, China's Environmental Protection Bureau. Etc.
II-Products:
2.1-Product series: Until today, we have 32 series of 230 products, such as products for treating transformer oil, refrigeration oil, turbine oil, waste engine oil, EH oil, hydraulic oil and mechanical oil and so on.
1/-Model ZLA Vacuum Transformer oil Filtering & purifying plant;
2/-Model ZLS Double stage Vacuum Transformer oil Filtering & purifying plant;
3/-Model BZ Transformer oil regeneration plant;
4/-Model ZLZ Multi-functional Transformer Oil Reclamation plant;
5/-Model JY Lubricant oil series purifier (for treating hydraulic oil, mechanaical oil, etc.);
6/-Model EJY oil water separator(for treating Anthracene oil, fuel, bunker oil, etc.);
7/-Model KRZ Phosphate ester fluids purifier (for treating ester oil, HFC oil, etc.);
8/-Model ZLR Refrigerant oil purifier (for treating refrigeration oil, compressor oil, etc.);
9/-Model ZZ Vacuum X-ray Tube processor and reloading System;
10/-Model ZLC Cable oil vacuum degasifier;
11/-Model ZLP Transformer oil PCB Decontamination plant;
12/-Model SY Automatic Transformer Oil Tester;
13/-Model GL Portable Oil Filtering Plant;
14/-Model TY Turbine oil filtering and vacuum purifying plant;
15/-Model JYW Waste Engine oil or motor oil recycling plant.
2.2-Applying areas: Our products and technology have been widely used in the fields of petroleum, petrochemical, power, mechanical, mining, aviation, shipping, railway, pharmaceutical, metallurgical, army, motor manufacturing industry and food processing industry, etc.
Our products have been used in more than 10,000 enterprises and exported to the USA, Japan, Germany and other 30 countries and regions. Products are also used by Taiwan Railway Bureau Co., Ltd., Nuclear Power Station of Taiwan, Nuclear Power Station of Pakistan, China's National Day Military Review, troops in Hong Kong and troops in Macao, and so on.
III-Welcome visiting:
Our Oil Purifier not only features advanced techniques, also perfect functions and high quality. It can give all customers reliable quality guarantee, reasonable price and good after-sales service. We are glad to cooperate with those who are interested in our products, and welcome you to visit our factory. If you want to know more information about our products, don't be hesitated, please contact us!
To be frank, to many similar factories here, we STRONGLY recommend you visit us in China.
