High performance automatic broiler chicken farming equipment

Main System for automatic broiler chicken farming equipment:

Name

Main Function

1.Main feeding  system

Convery feed from silo or main feed hopper into feedling line hopper automatically

2.Vice feeding  system

Convery feed into feeder pan automatically

3.Nipple drinking system

Supply clean water to each nipple steady, chicken can drink water from 360 degree freely

4.Ventilation system

Make chicken shed keep suitable temperature for different stage chicken

5.Environment control system

Setting suitable climate situation according to different stage chicken requirement,   through control ventilation fans, airlet and cooling pad's on /off to control  the chicken climate automatically.

6.Cooling system

Make chicken house tempeture come down quickly

7.Spraying system

Clean chicken house, chicken house disinfection

8.Heating system

Warm chicken house

Name

Features:

Chicken  feed silo

1).Silo with standard ladder and guard railing is safe and reliable.

2).Solid connection and good sealing performance.

3).Steel sheet galvanized ensure a service life of more than 10 years.

4).Model: 1.8M,2.75M,3.05M,3.6M;

   Capacity:2.5T to 27T;

Manpower hopper

 (can replace silo)

1).Material: hot dip galvanized sheet of more than 10 years life span.

2).Capacity:400kg-800kg

3).Advantage:keep feed fresh

4).Can be used for small farm projects.

Driving  Motor

Power:0.75kw; Voltage:380V ;

frequency :50HZ/60HZ, three phase AC current.

Feed level sensor:

Germany IFM feed level sensor.

Feed Conveying:

Diameter of conveying pipe:75*3.6mm ; Material: PVC

Helical spring auger from South Africa;  Feeding ability: 1,400kg/h, Maximum

Coveying lenrth:60m;  Radius of bending pipe: R1500-2000

Main components

Features&Function

Vice hopper

hot-dip double layer 275g galvanized sheet

(70kg, 90kg,120kg,150kg are optional).

Feed bolts

Interface diameter is 45mm, including galvanized grid

Feed pipe

double sided galvanized layer thickness of not less than 275g / m2,

diameter 45mm, 3m /pc ( 3-hole; 4-hole option)

Helical auger

Imported from South Africa

Feed pan

16 grill feed pan, ensure enough feeding space,

from day old chicks to grow up chicken are reliable,

Red PP material durable, easier to attract the birds feed.

Control pan

Including imported feed sensor, High sensitivity

Suspension system

Consist of steel wire rope, nylon rope, clips,winch,pulley,etc.

Driving motor

Power:0.75kw/1.1kw/1.5kw,

Voltage:380Vor 220V,

Frequency:50hz/60hz,

three phase/single phase

Main components

Features&Function

Front part of watering system

Adjust water supplying pressure and stabilizing drinking volume,

this part is usually installed in control system.

Nipples with drip cup

3m/12nipples

3m/15nipples are optional

Lifting and suspension system

Correct height for drinking system is very important for chicken

(both higher and lower can effect chicken bone’s distortion , it’s bad for chicken growth, and also can have some water wasting),

it’s very easy to adjust drinking system’s height if use this system.

Water display level tube

Use high transparency & impact resistant material,

it’s sturdy and durable, and convenient to watch water level.

This device with advanced design, it’s very easy to take down and clean.

Pressure regulator

a).Regulating stability, high switching performance,

b).water supply is sufficient& equality,

c).recoil cleaning with good cleaning result

d). can save time and water.

Doser

a).Can add medicine into drinking system automatically.

b).Don’t use power, it’s economic and reliable.

c).Accurate, after setting, it can adjust medicine volume according to water pressure change.

d).Its easy to control and maintain with good corrosion resistance.

Thickness

100mm;150mm

Width

300mm;600mm

Height

1660mm;1960mm;2160mm

Frame

Galvanized sheedt and Aluminium alloy

Aluminium alloy frame

High strength, good corrsion resistance, water distribution uniformity,beautiful and practical.

Performance parameters

50” fan

36”fan

Air capacity

43070m3/h

20800m3/h

Size

1380mmx1380mmx450mm

1000mmx1000mmx450mm

Noise

65db

64db

Power

1.1KW

0.4kw

Voltage

380/220V, or as requirement

380/220V, or as requirement

Current

2.8A

1.6A

Weight

88KG

66KG
