2016 Hot Sale Automatic Poultry Farm Equipment For Broiler Chicken

2016 Hot Sale Automatic Poultry Farm Equipment For Broiler Chicken

Brand: U-Best

What we could do for you - Automatic Poultry Farm Equipment :

A. Produce and supply first-class poultry equipment;

B. Select location of poultry house;

C. Poultry house design and construction preparation Guidance;

D. Breeding workers training;

E. Poultry equipment installation;

F. After-sales service

What you need to provide for us to make a good offer for you:

1. How many broilers do you plan to feed?

2.Is the area of your poultry house confirmed, including the length,width and height?

3. what's your raising period and the final weight for sale in market?

4. where is your poultry farm located in, in which country? How about the climate there, temperature and humidity rate..?

 Automatic Poultry Farm Equipment consists of:

1. Main stock line of silo/manpower hopper system

2. Automatic pan feeding system

3. Automatic nipple drinking system

4. Automatic ventilation system

5. Cooling pad system

6. Environmental and Power control system

7. Spraying and disinfecting system

8. Heater

1. Main stock line of silo/manpower hopper system

Main feed line: silo/manpower hopper is the beginning of main feed line. There is a feed sensor at the end of main feed line which controls motor on and off to achieve automatic feed delivery.

Silo

2. Automatic pan feeding system

Automatic pan feeding system consists of a driving motor, a hopper, a conveying pipe, an auger, feed pan, a suspension lifting device, an anti-perching device and a feed sensor.

Performance Parameters:

3. Automatic nipple drinking system

This system can provide fresh and clean water for poultry which is crucial for the growth of poultry. The drinkers can be triggered from 360 degree which helps young birds start well and makes drinking easily.

Poultry Nipple Drinking System consists of:

(1) Front Part of Drinking System

(2)Water Pipe Installed With Nipple Drinkers

(3) Pressure Regulator

(4) Water Display Level Pipe

(5) Lifting and Suspension System

4. Automatic ventilation system

This system controls climate conditions, fresh air, humidity and temperature in poultry shed. It is vital for growing birds, including air inlets, axial flow fan and butterfly cone fan for your choice

5. Cooling pad system

Cooling pad and fan, the longitudinal ventilation and cooling combination is the most economic and effective summer cooling system for poultry house.

Parameters:

Color: black, yellow

Thickness specification: 100mm, 150mm

Width specification: 300mm, 600mm

Height specification: 1660mm, 1960mm, 2160mm

Outer frame: aluminum alloy, high strength, good corrosion resistance, even water distribution, compact structure, beautiful and practical.

6. Environmental control system

This system saves labors and resources under the condition of assuring a optimum growth environment for poultry chickens. It is imported from Israel which can set an optimum working mode according to the local climate and raising environment.

7. Spraying and disinfecting system

This system effectively cools, humidifies, remove dusts and disinfects poultry house(temperature could be quickly reduced by 3-8 degrees centigrade within a few minutes)

A. humidification: increase the humidity to the preset range according to the requirements - 60~70% of the maximum relative humidity.

B. cooling: cooling poultry house by 3~8 centigrade within few minutes.

C. disinfection: add disinfectant into water source of spraying and fogging system, then fogging system could disinfect the chicken house.

D. washing: the Spraying Machine could also do wash for chicken house.

8. Heater

Heating poultry house when it is needed to satisfy the temperature demand of chickens at different growth stage. Hot-blast heater of coal and diesel, poultry gas heater, infrared gas brooder and fan-heater of gas/diesel, 4 different kind at your option.

Packaging and Shipping

Standard export package of automatic poultry farming equipment for export is in container. Shipment in 15 days after the order confirmation.

1. silo: disassembled, spare parts in carton box, galvanized sheet in bunch and in bulk;

2. feeder: feeder pan in carton box, feed pipe in bunch in bulk;

hopper in bulk;

3. water: PVC pipe fitted with nipples in plastic bag, cups and spare parts in carton box; support pipe: in bunch in bulk;

4. fans: disassembled way or assembled way;

5. air inlet: HB620 4pcs per carton box; HB1100 disassembled in carton box;

6. cooling pad: Assembled with aluminium frame, or disassembled;

7. heater: in Carton box

8. fogging system: handcart wrapped with plastic shrink, spare parts in  carton box

9. enviroment control: In carton box;

Company Introduction:

Weifang U-Best Husbandry Equipment Co.,Ltd

We are professional manufacturer and supplier of automatic poultry farm equipment in China!

Our equipment has passed ISO9001:2008 Quality Management System Certification!

We have our own production line so we can control the quality very well, and our quality reaches European standard!

Our automatic poultry farm equipment has been exported to more than 30 countries and have good market reputation!

We have many different project of chicken farm in Indonesia, Philippines, Columbia, Costa Rica, Sudan, Zimbabwe, Mozambique, Qatar, Dominica, Saudi Arabia and Fiji etc.

Welcome to contact Ms. COCO in U-Best company!
