Tunnel type Food Processing Machinery microwave dehydrated onion powder machine
1.Application:
This machine fits for drying and sterilizing powder ,granular, sheet-like or gel-like food ,and additive, flavoring, medicine, raw material of herbal medicine, nutritional health products, agriculture & sideline products, non-fried(or oil-saving)instant noodles, noodles, rice powder noodles, soy products, beef jerky, preserved meat, dried fish ,tea, tobacco and so on; and for drying, peeling and baking almond, peach kernel, groundnut kernels, chestnut and so on; and for puffing of leisure food ,pachyrhizus chips, potato chips, dried shrimps, fish maw and so on; and for sterilizing and oral liquor, pickles, a variety of small packaging food ;and for drying beans; and for thawing the frozen fish ,poultry; and for drying and desulfurating and deoxidizing the metallurgical chemical products; and for drying printing and dyeing products, ceramics, glass, chemical fiber, cotton yarn, wood, leather, bamboo products, insulation materials, building materials, cork, alveolate cardboard, corrugated ,and so on.
2.Introduction:
I. Introduction to the equipment
It adopts the technology of radiation with several microwave sources and it is equipped with imported temperature controller, The heat is distributed evenly. It is installed suppresser against the microwave leakage at the heater’s inlet and outlet for the materials. Its leakage index has met America UL standard, we can assure it is absolutely safe. During the course of roasting, the dried onion on the trays can rotate at stepless speed that is convenient for the adjustment of various technologies.
II. The features of drying and sterilizing
1.High efficiency, energy saving, evenly heating. Microwave has excellent penetrability, It can penetrate into the inside of the dried onion, heating it inside and outside at the same time, besides, only the dried onion which is heated can absorb the microwave energy. Therefore, it has high thermal efficiency and the heat is homogeneously distributed that diminish the loss of heat energy. Compared with general electrothermal drying method, 1/3 to 1/2 of electricity can be saved.
2.Good result of low-temperature sterilization, both thermal effect and nonthermal effect. Compared with regular method, it is characterized by low temperature and fast speed. It can keep the origional color,pleasant smell, taste without spoiling the nutritious components and has good expanding effect. The taste of the food is excellent.
3.It is convenient and quickly to control it without being affected by the weather. There is no heat inertia of the microwave equipment. The microwave power and transmission speed can be regulated continuously. This equipment can keep producing last for 24 hours.
4.There is no heat radiation of the microwave equipment itself when heating, so this can improve the work condition. The microwave leakage conforms to national standard. It has compact structure with less land area occupied.
3.Reference technical parameters:
Power supply |
380V±10% 50HZ±1% three-phase five-wire |
Microwave Output Frequency |
2450±50MHz |
Microwave input apparent power |
≤42KVA |
Microwave output power |
≥30KW |
Microwave power adjustment range |
0-30KW(adjustable) |
Ambient temperature |
-5-40°C |
Relative humidity |
≤80%, Surrounding environment:no corrosive gas, conductive dust and explosive gas |
Overall dimension(L*W*H) |
about10680*840*1750 mm |
Transmission speed |
0-10m/min(adjustable) |
Height of the inlet and outlet |
60 mm |
Microwave leak |
accord with a country GB10436-89 standards(<5 mw/cm^2) |
Equipment safety |
accord with GB-5226Electrical safety standard accord with a country GB16798-1997 Food machinery |
packing and shiping:
Please contact me to talk more details!
