Description
belt dryer through flow dier aree widly used in dields of food, agriculture productsand by-products, dehydrated vegetable, chinese herbal medicine, fish products, feed and chemical industry and are suitable for drying of flaked, striped, cube and granule materials.
The drier has the characteristics of high efficiency and Iow energy consumption and possess the domestic advanced level in through flow drying, leading wind layer by large, drying by changing temperature stage by stage and collecting remainder heating, Main specifications have reached 90's adanced interational level.
The belt conveyor of this drier that loads drying material is five layers stainless steel net belt,
Because the hot flow bellow to above belt layers, heating exvhange completly and evenly, production efficiency is high and the product quality are very good. There are cooling layer and vibration device in outlet to . decrease the final product temperature and make it convenient to package in time. These driers are equipped with elevator with material even device to make the height of material identical, the height of material can be adjusted by nostep.
These driers have five styles, with belt area from 25~70m2,it can meet the requirement of drying many kinds of materials and different product scale. Our factory can provide technical serves for consultation, equipment selection, research & design and undertaking engineering.
Technical parameters
| itemmodel | GWC-20 | GWC-25 | GWC-32 4m | GWC-36 4.5m | GWC-48 6m | GWC-60 7.5m | GWC-80 10m |
| loading area m2 | 20 | 25 | 32 | 36 | 48 | 60 | 80 |
| stream pressure Mpa | 0.4-0.7 | ||||||
| stream consumption kg/h | 150-300 | 180-375 | 240-480 | 270-540 | 360-720 | 450-900 | 600-1200 |
| drying period min | 20200 | 60600 | 1001000 | ||||
| evaporating capcity kg·H2O/h | 100-200 | 125-250 | 160-320 | 180-360 | 300-480 | 300-600 | 400-800 |
| power Kw | 5.5 | 5.5 | 5.5 | 5.5 | 14.2 | 15.2 | 15.2 |
| weight t | 8 | 8 | 8.5 | 10 | 11 | 13 | 15 |
| overall dim.mm | 8875 ×2408 ×3385 |
9875 ×2408 ×3385 |
11475 ×2408 ×3385 |
11475 ×2408 ×3385 |
14675 ×2408 ×3385 |
14675 ×2840 ×3385 |
15675 ×2840 ×3385 |
Company introduction:
Changzhou No.2 Drying Equipment Factory Co.,Ltd is an old drying enterprise which has 23 years drying history. We have got several patents in different dryers. We have much experience in different drying area. Now it holds more than 100 sets of equipment. The company has more than 100 staff and workers, including 15 engineers, with annual value of production more than thirty-eight million RMB.We attach importance to advanced technology, and have cooperated positively with universities and colleges to develop new products by using new technics. We have continuously developed several key and high-tech products with advanced technology both from domestic and abroad.During the past ten continuous years, the company has been appraised as enterprise with high reputation on contract and credit.Bases on the principle of factualism, innovation and mutual benefit, the enterprise is looking forward to creating resplendence with personages from all circles together.
Certificate and Letters Patent:
Service:
The Warranty Period of the dryer machine shall be 12 months from the date of completion of the installation and commissioning of the Contract.
We will provide some spare parts for free together with dryer before shipping, paid service will be provided for the long term, and we can provide components at competitive price.
