Apricot Dryer Machine

Name: Apricot Dryer Machine
Brand: chang gan
SKU: 137284085
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

chang gan

Model Number:

DWT

Contact Supplier Request Quote Chat Now

Changzhou No. 2 Drying Equipment Factory Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name chang gan

Model Number DWT

After-sales Service Provided Engineers available to service machinery overseas

DWT Series Mesh-Belt Drier

Application
Dryer machine is flowing and continuous type drying equipment firstly made by our factory. The machine is used for drying the piece, tape and particle state materials with good ventilation. The machine is suitable for the materials, such as de-watering vegetable, herbal medicine of traditional Chinese medicine and others, for which the water content rate is high and the high temperature is not allowed. The machine owns the advantages, that its drying speed is fast, the evaporation strength is high and the product quality is good. The de-watering filtering cake state paste material, after the particle making or bar making, can be dried also.

Principle of work
The materials are uniformly put on the mesh-belt by the material charger. The mesh-belt uses generally 12 - 60 mesh stainless steel wire net and it is drawn and moved inside the drier by a transmission device. The drier iscomposed of several units. For each unit, the hot air is circulated separately. In the first unit, air out from circutation air blower(5) pass through beside into Iow unit, after air is up and heated by steam heater(4),be shared by seperater(3), the air is spraied through mesh-belt in to top of machine. The drying process is hot air passes through the mesh-belt covered with a special moisture from the top to the bottom or from the bottom to the top,and this will complete the heat and mass transfer process. The air pipe of the top is conected with fan, one part of air is circulated, some exhausted gas is discharged with a special moisture eilmination blower, and other waste gas is controlled through an adjustment valve. The top and Iow circulation units can be freely equipped according to the users' demand,The unit nomber can be selected according to the demand.

Technical parameters

type	DWT-1.2-8	DWT-1.2-10	DWT-1.6-8	DWT-1.6-10	DWT-2-8	DWT-2-10
unit number	4	5	4	5	4	5
belt width m	1.2	1.2	1.6	1.6	2	2
drying section length m	8	10	8	10	8	10
thickness of the material to be covered mm	1080
temperature	60150
steam pressure Mpa	0.20.8
steam consumption kg/h	120300	150375	150375	170470	180500	225600
drying time h	0.21.2	0.251.5	0.21.2	0.251.5	0.21.2	0.251.5
drying strength kgH₂O/h	60160	80220	75220	95250	100260	120300
total power of the blower KW	8.8	11	12	15	16	20
total power of the equipment KW	10.1	12.3	13.3	16.3	17.3	21.3

Company introduction:

Changzhou No.2 Drying Equipment Factory Co.,Ltd is an old drying enterprise which has 23 years drying history. We have got several patents in different dryers. We have much experience in different drying area. Now it holds more than 100 sets of equipment. The company has more than 100 staff and workers, including 15 engineers, with annual value of production more than thirty-eight million RMB.We attach importance to advanced technology, and have cooperated positively with universities and colleges to develop new products by using new technics. We have continuously developed several key and high-tech products with advanced technology both from domestic and abroad.During the past ten continuous years, the company has been appraised as enterprise with high reputation on contract and credit.Bases on the principle of factualism, innovation and mutual benefit, the enterprise is looking forward to creating resplendence with personages from all circles together.

Certificate and Letters Patent:

Service:

The Warranty Period of the dryer machine shall be 12 months from the date of completion of the installation and commissioning of the Contract.

We will provide some spare parts for free together with dryer before shipping, paid service will be provided for the long term, and we can provide components at competitive price.
