Help CenterSG Series Channel Hot Air Oven
Related Products
CT-C series oven is our factory initiate product of our country, was upgraded and regenerated for several times and has reached to advanced level both at China and all over the world. The CT series is the first generation product, average heat efficiency about 30%, adapt centrifugal fan, box body out circle, handwork control temperature way. Through many times reformation, form the CT-C series oven, the series all adopt axes flow fan, match with auto constant temperature control system, and have computer control system for choice. The heat efficiency reach about 70% , it use seam or electric heater as heating source, use axial fan, heat exchanger to heat air in convective way. The laminar flow of hot air passes through the baking trays and will carry out heat transmission with material. Fresh air will enter into the oven from inlet to supply and then discharge from damp outlet. Fresh air is supplied, wet and hot air is discharged continuously. In this way, suitable RH in saves energy source, which makes thermal efficiency of oven raise from 3-8% of traditional drying oven to about 35-50%. Before application, customer can adjust fan blade in order to make the temperature difference at the best state.
Feature:
1. the customer can according material's characteristic to choose lengthways circle and landscape orientation drying mode, to improve the efficiency and product's quality.
2. can adapt centralized heating way, it's in favor of coal fuel, oil fuel, gas fuel hot air furnace, conduct oil furnace etc. heating source connect, it's convenience for customer using.
3.according to customer requirement, can adapt manpower and mechanism way to fee-in and feed -out.
Technical parameter:
Type |
Feeding capacity(Kg) |
Equipped power(Kw) |
Drying car |
Drying tray |
Radiation area(m2) |
SG-11 |
1000 |
20.2 |
22 |
528 |
200 |
SG-16 |
1500 |
26.2 |
30 |
720 |
300 |
SG-22 |
2000 |
32.2 |
40 |
960 |
400 |
SG-30 |
2500 |
38.2 |
50 |
1200 |
500 |
SG-36 |
3000 |
38.2 |
60 |
1440 |
600 |
