Fiberglass Mesh Machine
US$ 1 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, Fiberglass mesh machine
Place of Origin:
Hebei, China
Payment & Shipping
Payment Methods:
Port of Shipment:
xingang and so on
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Product Type
Other, Fiberglass mesh machine
Place of Origin
Hebei, China
Brand Name
tuohua
Model Number
THJQMACHINE-005
Specifications
Fiberglass mesh machine is received by customer due to excellent property and quality of the fiberglass screen produced with itFiberglass Mesh Machine
1. Width scope of weaving: 1-2m
2. Mesh scope of weaving: 3-10mm
3. The machine is controlled by PLC automatic controller, so only one person is needed to operate it
4. The output :400-1000m/day
5. Use compacting machine to make it into rolls
Specification:
Fiberglass Mesh Machine | |
Mode |
AET788 |
Reed width |
150≈360 CM |
Loom Speed |
90≈140/min |
Weft stop |
Control of piezoelectric ceramic |
Warp stop |
4 stopped by the electrical device |
Motor power |
1.5KW |
Motor speed |
960/Min |
Weiht |
1700≈2800KG |
Fiberglass Insect Screening Weaving Machine
This fiberglass screen machine is well received by our customers due to its excellent property and the quality of the fiberglass screen produced with it.
Major Index:
1.Electric Motor: 1.5KW FOH-56-6, 2.0KW FOH-58-6, 960rotation/minuts
2.Max. shaft rotation: 130-200 rotation/minute
3.Weft yarn choice: mechanical control, six color
4.Weaving shaft coil distance(mm):1380,1860,2060,2366,2566,2866
5.Weaving shaft coil diameter(mm): 550, 600
6.Cloth Full Rolling Diameter(mm): 400
7.Warp Yarn Feeding: Auto feeding
8.Weft Yarn Feeding: Auto feeding
Outside Dimension of the machine(mm):
1.width:3875, 4180, 4380, 4680, 4880, 5180
2.Depth: 1857; Height:1640
3.Weight of the Machine: 1700-2800kg (motor not included)
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2010
Factory Size
10,000-30,000 square meters
Total Employees
101 - 200 People
