Help CenterWelded Mesh Machine
US$ 5,000 - 25,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
tuohua
Model Number:
THJQMACHINE-001
Payment & Shipping
Payment Methods:
Port of Shipment:
xingang and so on
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Hebei, China
Brand Name
tuohua
Model Number
THJQMACHINE-001
Specifications
Welded Mesh Machine used in iron wire or stainless steel welded mesh. High stability,low noise,quickly speed,save electricity.Welded Mesh Machine
Description:
1).size of mesh:12.7mm-101.6mm(1/2"-4")
2).width: 914.4-1219.2mm(12"-48")
3).diameter of wire: Φ0.63- Φ2mm(BWG25-BWG19)
4). Biggest rolled net size: 120m(400')
5).Welding speed: 65radia (mesh/minute)
6).Power: 380/220V 50-60Hz 50KWA×4
Type and Specification:
1.Used for welded wire mesh 1/4"-1/2".
1).characteristics:Box-style support high stability,lower noise,E-Machine in one,straighten & send wire automatically.
2).Specification:
| Size of mesh (mm) | 6.35-12.7 (1/4"-1/2") |
| Width (mm) | 914.4-1219.2(12"-48") |
| Diameter of wire (mm) | dia.0.45-dia.1.07 (BWG25-BWG19) |
| Biggest rolled net size (m) | 120m (400') |
| Welding speed (mesh/minute) | 75 (radia) |
| Power | 380/220V,50-60HZ,50KWA x 4 |
| Outside size measurement (mm) | 2350 x 1820 x 1700 |
1).characteristics:Box-style support, high stability, lower noise, E-machine in one, straighten and send wire automatically.
2).Specification:
3.Used for welding net of big width,Wire diameter from 0.7mm to 1.07mm; mesh 1/4" to 1/2".
2).Specification:
| Size of mesh (mm) | 12.7-101.6 (1/2"-4") |
| Width (mm) | 914.4-1219.2(12"-48") |
| Diameter of wire (mm) | dia.0.63-dia.2(BWG25-BWG19) |
| Biggest rolled net size (m) | 120m (400') |
| Welding speed (mesh/minute) | 65 (radia) |
| Power | 380/220V, 50-60HZ, 50KWA x 4 |
| Outside size measurement (mm) | 2600 x 1700 x 1350 |
3.Used for welding net of big width,Wire diameter from 0.7mm to 1.07mm; mesh 1/4" to 1/2".
1).characteristics:Shuttle sending weft wire type, sending quicker, lower noise, more stable, save electricity.
2).Specification:
4.used for welded wire mesh of big width and wire diameter.
2).Specification:
| Size of mesh (mm) | 6.35-12.7 (1/4"-1/2") |
| Width (mm) | 1219.2-1828.8(48"-60") |
| Diameter of wire (mm) | dia.0.74-dia.1.07 (BWG22-BWG19) |
| Biggest rolled net size (m) | 120m (400') |
| Welding speed (mesh/minute) | 48 (radia) |
| Power | 380/220V, 50-60HZ, 50KWA x 6 |
| Outside size measurement (mm) | 3050 x 1900 x 1750 |
1).characteristics:Box-style support, high stability, lower noise, E-machine in one, straighten and send wire automatically.
2).Specification:
The mainly use of welded Wire Mesh Machine:
1 construction mesh(terrestrial heat mesh, wall board mesh, greenhouse mesh).
2 welding machine, automatic welding machine, aluminum welding machine can be used in the building roof, chain link fence and so on.
The characteristics of Welded Wire Mesh Machine:
High stability,low noise.It straight the wire and feeding automatically,quickly speed and save electricity.
2).Specification:
| Size of mesh (mm) | 25.4-152.4 (1"-6") |
| Width (mm) | 1219.2 1524 1828.8(48" 60" 72") |
| Diameter of wire (mm) | dia.1.07-dia.2 (BWG19-BWG14) |
| Biggest rolled net size (m) | 91.4m (300') |
| Welding speed (mesh/minute) | 45 (radia) |
| Power | 380/220V, 50-60HZ, 50KWA x 6 |
| Outside size measurement (mm) | 3350 x 1800 x 1400 |
The mainly use of welded Wire Mesh Machine:
1 construction mesh(terrestrial heat mesh, wall board mesh, greenhouse mesh).
2 welding machine, automatic welding machine, aluminum welding machine can be used in the building roof, chain link fence and so on.
The characteristics of Welded Wire Mesh Machine:
High stability,low noise.It straight the wire and feeding automatically,quickly speed and save electricity.
