Mobile Stone Crusher for Aggregate Crushing Process, easy movable mobile crusher plant for sale 5% Discount
Main Customer Benefits of Mobile crusher for aggregates
- High crushing speed, together with large feed opening, provides impressive rates of production, yet able to provide superb reduction ratios
- Hydraulically adjustable CSS for a variety of applications
- Reverse crushing action to relieve blockages and automatic central lubrication system to increase machine up-time
- Hydraulic legs for increased stability and servicing capabilities
- Global aftermarket support, with standard stock parts to ensure minimum loss of production
- Machine designed for optimum fuel
About DSMAC - Mobile crusher for aggregates
Founded in 1997, DSMAC Group is a mobile crusher manufacturer.we have mobile jaw crusher ,mobile impact crusher,mobile cone crusher ,Mobile VSI Crusher and Portable Crawler Crusher.
DMP Series Application of Mobile crusher for aggregates
1.Quarrying and surface mining
2.Road construction aggregates
3.Crushing contractors
4.Aggregate production
5.Primarily any mineral application that requires precision compact crushing delivered at high production rates and where mobility is at a premium.
Payment & shipping terms of Mobile crusher for aggregates
1.Price:FOB USD 10000-99999/Set(negotiation)
2.Minimum Order Quanlit(MOQ):1 Set
3.Port:Shanghai;tianjin;qingdao
4.Packaging Details:Standard Container, Nude Packs or in Bulk.
5.Delivery Time:15-30 days
6.Payment Terms:L/C,T/T
7.Supply Ability:100 Set/Sets per Month
If you want to get the price, please send us the detailed materials information, such as the hardness of raw materials,feeding size, you required output size,capacity and other special requirement.Our engineer will choose the optimum type and our saleman will send you the resonable price.
DMP Series Mobile crusher for aggregates
DMP JAW PLANTS |
DMP600 |
DMP750 |
DMP900 |
DMP1060 |
DMP1200 |
|
transport dimension |
Length(mm) |
8600 |
9600 |
11097 |
13300 |
15800 |
Width(mm) |
2520 |
2520 |
3759 |
2900 |
2900 |
|
Height(mm) |
3770 |
3500 |
3500 |
4440 |
4500 |
|
Weight(kg) |
15240 |
22000 |
32270 |
57880 |
98000 |
|
Axle weight(kg) |
10121 |
14500 |
21380 |
38430 |
64000 |
|
King pin weight(kg) |
5110 |
7500 |
10890 |
19450 |
34000 |
|
Jaw crusher |
Model |
PE400*600 |
PE500*750 |
PE600*900 |
PE750*1060 |
PE900*1200 |
Feed opening(mm) |
400*600 |
500*750 |
600*900 |
75*1060 |
90*1200 |
|
Setting range(mm) |
40-100 |
50-100 |
65-180 |
80-180 |
95-225 |
|
Capacity(m3/h) |
10-35 |
25-60 |
30-85 |
70-150 |
100-240 |
|
Feeder |
Model |
GZT0724 |
GZT0724 |
GZT0932Y |
ZSW200 |
ZSW300 |
Feed hopper volume(m3) |
3 |
4 |
7 |
10 |
10 |
|
Hopper width(mm) |
2200 |
2500 |
3000 |
3000 |
3000 |
|
Belt conveyor |
Model |
B650*6 |
B800*7 |
B1000*8 |
B1000*11 |
B1200*13 |
