Submersible Solar Water Pump for Irrigation (440W,20M Head)

Name: Submersible Solar Water Pump for Irrigation (440W,20M Head)
Brand: Submersible Solar Water Pump,FADI,OEM
SKU: 134510063

US$ 500 - 5,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Submersible Solar Water Pump,FADI,OEM

Model Number:

FD-SWP20M-440W

Haining Fadi Solar Energy Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Submersible Solar Water Pump,FADI,OEM

Model Number FD-SWP20M-440W

Theory Centrifugal Pump

Structure Multistage Pump

Usage Water

Power Electric

Standard or Nonstandard Standard

Fuel Other, solar

Pressure High Pressure

Application Submersible

Submersible solar water pump

Model:FD-SWP20M-440W.

Submersible solar water pump features:

.Structure, high-lift, noiseless, pollution-free;

.Complete electrical protecting controller device, against under-voltage, over-voltage, over-flow, over-load, waterless, etc;

.Automatically recovery;

.Control water height;

.Easy installation, maintenance-free, safe, reliable, energy-saving, efficient;

.Photovoltaic water pump, Permanent magnet brushless motor, Maximum power point tracking(MPPT)

.Ambient temperature -20°C-50°C

.Service life over 10 years

Solar water pump system working principle:

Solar water pump system data

Model	FD-SWP20M-440W
Max flow	2.7M³/h
Max head	20M
Voltage	24V
Power	440W poly-crystalline panel (4pcsx110w)
Pump diameter	2inch
Outlet	1 inch
G.W.	4kgs
warranty	Two years
Submersible solar water pump
Pump casing	Stainless steel
Screw	Stainless steel
Shaft core	Stainless steel
Coupling	Stainless steel
Connecting	Copper alloy
Base	Copper alloy
Cable	Rubber
Water level sensor	Rubber + Plastic
Submersible solar water pump compents
Solar pump	1pc
Controller box	1pc MPPT
Screw	1pc
Cable connector	4pcs
Water level sensor	4pcs
Rope	1pc
Manual	1pc
Submersible solar water pump working condition
Liquid	Non-corrosive water
Volume ration of sand content	Less than 0.1%
Size of sand content	Less than 0.2mm
Max medium temperature	Less than 40°C
PH	6.5-8.5
Situation	Be immersed in water
Application	Pumping water from deep well, gardening, fountain and etc
