Help CenterLFP1050-1100N Series Nano Filtration Booster Pump
Related Products
LFP1050-1100N Series Nano Filtration Booster Pump
The wet parts complies food grade requirements ;
The pressure-containing member adopts high strength plastic and metal materials;
The materials of sealing parts are all imported;
Equipped with high power DC motor with low noise,low vibration;
Totally inspection control in production process for electrical, sealing and water;
Nano filtration diaphragm pump is both storing pressure and self suction function;
PRODUCT PARAMETERS
LFP105N SERIES |
Parameter |
LFP1075N SERIES |
Parameter |
LFP1200N SERIES |
Parameter |
Model |
LFP1050N |
Model |
LFP1075N |
Model |
LFP1100N |
Voltage |
24VDC |
Voltage |
24VDC |
Voltage |
24VDC |
Connection Thread |
3/8"NPT(general) |
Connection Thread |
3/8"NPT(general) |
Connection Thread |
3/8"NPT(general) |
Inlet water pressure |
0MPa |
Inlet water pressure |
0MPa |
Inlet water pressure |
0MPa |
Operating pressure |
0.35MPa |
Operating pressure |
0.35MPa |
Operating pressure |
0.35MPa |
Current |
≤0.7A |
Current |
≤0.7A |
Current |
≤0.7A |
Work flow |
≥550mL/min |
Work flow |
≥750mL/min |
Work flow |
≥980mL/min |
Open flow |
≥1000mL/min |
Open flow |
≥1150mL/min |
Open flow |
≥1300mL/min |
Max Pressure |
0.5-0.55MPa |
Max Pressure |
0.5-0.55MPa |
Max Pressure |
0.5-0.55MPa |
Max Current |
0.96A |
Max Current |
1.0A |
Max Current |
1.25A |
Compliant with ROHS & CE certification
