200-300KN Multi-function electronic tensile machine
1. Introduction
ZY series multifunction electronic testing machine for stretching a variety of materials, compression, bending, shearing, tearing, peeling and other mechanical properties measured at the end.
This machine is gantry frame, the appearance of new and generous. Computer digital control system, equipped with a force sensor and elongation automatic tracking device, good stability. Electric use PC and interface board for data collection, preservation, processing and printing test results, calculate the most vigorous, yield strength, average peeling force, maximum deformation at the end of some material basic physical performance parameters. During the test, the computer real-time acquisition force value and deformation signal, the software displays "force value - displacement" curve, after the end of the test, calculated automatically, save the parameters, and can print out the report in the form of end user needs.
2, the structural principle
Host by the electronic control system, transmission, measuring system and elongation automatic tracking device component.
Electronic speed control system: This machine adopts AC variable speed, corresponding to a tensile speed of 1-Xmm / min (X for the end user requirements), with the highest return rate.
Transmission mechanism: motor driven screw drive through, two synchronous drive screw move the bar.
Measuring system: installed in the main moving force sensor beam (sensor only by vertical force, without measuring torque and force) to ensure accurate dynamometer during the test, a sample of the forces into electrical signals by the sensor input.
Elongation tracking means: the means for measuring deformation of the sample, by an external tracker, tracker may also be a built-in track. Also available without a tracker, by a motor built deforming device tracking.
3, the main technical parameters
3.1 force value resolution: 0.01N
3.2 System accuracy: less than ± 0.3%
3.3 speed range: 0-150mm / min (special requirements can be separately)
3.4 elongation tracking error: ± 0.1mm
3.5 Power supply voltage: AC380V ± 10% 50Hz
3.6 dimensions (length × width × height): 750 × 660 × 2010
3.7 Weight: 400KG
The multi-functional electronic tensile machine features
Automatically cleared: After the computer controlled test command, the system automatically cleared;
High intelligence: After the test, automatically determine fault, the clamp automatically returns to the initial position
Multifunctional: different clamps, different tests can be carried out;
Automatic transmission: according to the size of the load, switch between different grades;
Change the speed: You can test the speed of any change
Control method: test force, test speed, displacement, strain and other test methods.
Features super: the whole record test data. Provide save, contrast and tracking functions and services, use the mouse to find the test curve by any point of force value and deformation data analysis, and enlarged contrast.
Multiple protection: with automatic limit and automatic overload protection.
Calculated: automatic calculation of various test results, and to report any modification
Automatic length measurement: Equipped with high precision encoders, automatic measurement of displacement between stroke and punctuation elongation.
High Style: carved, smooth lines, with high precision and the ability to integrate hardware and software technologies, fully embodies the exquisite manufacturing technology and smart efforts.
5. Configure
1, double-column gantry.
2, high-precision sensor One only
3, high-precision photoelectric automatic tracking device
4, universal testing machine software with automatic computing, storage, contrast, and other functions
5, there are two manual operator panel and software operation panel select
6, high-precision military enterprises screw
7, high-performance motor drive, no noise, no vibration, smooth operation
8, special test fixtures
9,19-inch LCD computer Tsinghua Tongfang, HP color printer.
USE picture
