QT8-15 cheap widely used concrete block machine price in India
Our company is a famous designated enterprise by the state of brick and tile machinery specialized manufacturer, with over 40 years of history in producing the bricks. It is also the board company of China brick & tile association, and it has passed firstly ISO9001 international quality system certification, the quality of the products is under the insurance of PICC. And our product is free of national inspection.
Our company has many of excellent technicians, perfection technique equipments, advanced testing system and a whole quality assurance system. The products have a good market at home and abroad, and have exported to Russian, Sudan, Bengal, Egypt, Iraq, South Africa, and Mongolia and etc. nations, highly trusted and applauded by consumers.
Descriptions of HDQT8-15 used block machine :
1.Introduction of used block machine:
QT8-15 used block machine is a kind of equipment which uses slag, fly ash, stone dust, sand, gravel, cement and others as raw material, through material proportion, stirring and high-pressure moulding to make many kinds of bricks and blocks. It is also called non-burn block machine. That’s to say, the finished block can come into use only through drying by the solar power, no need sintering.
2. Working principle of used block machine:
This line hollow block making machine uses slag, fly ash, sand, gravel, cement and others as raw
material, through the stirring in proportion and the molding under high pressure, to complete the
block making.
Main Technical Specifications of HDQT8-15 used block machine | ||
Cycle Time: |
15-20 seconds |
|
|
Production per Shift (8 Working Hours): |
Hollow Block ( 390x190x190mm ): 11520-15360pcs |
|
|
Solid Block (220x115x72mm): 43200-57600pcs | ||
|
Interlock (225x112.5x60mm): 28800-38400pcs | ||
|
Holland Brick (200x100x60-80mm): 34560-46086pcs | ||
Vibrating Frequency: |
2940 rolls/minute or 50 HZ |
|
Vibrating Force: |
100 KN |
|
Motors Power: |
38 KW |
|
Machine Dimensions: |
5568x2060x2968mm (excluding electrical control box)' |
|
Pallet Size: |
1100*680*20mm |
|
Gross Weight: |
about 12T |
|
Raw Materials: |
crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes |
|
Applied Products: |
concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc. |
|
Applied Fields: |
widely used in buildings, road pavings, squares, gardens, landscaping, city constructions, etc |
|
Advantages Of QT8-15 used block machine:
1. Perfect humanization Electrical control system
LG PLC with Visualization touch screen provide you a Child operation machine.
2. Frequency Conversional Control Technology:
It guarantees the precise and parallel movement between tamper head and mould, protects the products from transfiguration; increases the production rate by improving the vibrating efficiency, and Power saving: 30%;
3. Hydraulic System. Make in China, world Quality , and we can provide you the hydraulic motor as you request .
4. Compulsory Feeding system make sure that the density and intensity of the products are guaranteed;
5. Various product scope:
It produces various color-face bricks (layered material feeding),through-body tiles,lock linkage blocks, road curb bricks, hydraulic blocks,hollow blocks, perforated bricks, and standard bricks etc.
Some used block machine accesories for reference
Batching Plant:: This is the starting point of the Production process. It consists of three loading bins and one weighing bin. It also contains blet conveyers to convey materials from loading bins to weighing bin. Batching and weighing is done by PLC control. We can load three different types of material into the loading bin.
Stacker:Stacker is used to lay the block automatically,it is high effiicent and labor saving.
Concrete Mixture Machine: All the ingredients are mixed in this mixture machine. The mixing time and speed is controlled by PLC. The inbuilt water pump adds water to the mix automatically, as per requirement.
Used block machine :This is the key of the production line.It can press the mixed material.It can make various hollow block,solid brick,paver brick and kerbston.
Designed Production lines of HDQT8-15 used block machine for reference
Our payment terms,
1. We usually accept T.T, or Cash, or L/C, 30% for down payment, 70% pay as balance before loading.
2. It is about 30days to finish all the machines after receive the down payment.
3. We take pictures and videos of finished products, and test all the machines before delivery.
Packaging of our machines:
1.Each small part of machine would be packed well, also we would arrange engineer to check each machine parts before delivery, so we can ensure buyer can get complete clay brick machine parts. .
2. Some parts will be given soft protection before feeding in the container to make sure all the machine will be new when arriving at customer hand.
Delivery of our machines:
1. We have been long term cooperation with many famous shipping agent. Also we can arrange the shipment as your needs.
2. After we get the B/L we will send it to you together with the Sales Contract, Invoice, Packaging List, etc.
Our used block machine , with harmonic cooperation between mechanical, electrical and hydraulic machines functions, guarantee a reliable and high output production of concrete products
A. LG PLC, with great adaptability, guarantees the stability and reliability of the machine.
B. Visualization touch screen, with easy operation;
2. Use Frequency Conversional Control Technology, which controls the block making:
A. Frequency Conversion Control: guarantees the precise and parallel movement between tamper head and mould, protects the products from transfiguration; increases the production rate by improving the vibrating efficiency;
B. Controls the instantaneous start and stop of the motors, to protect the motor from over-heating caused by constant working;
C. Power saving: 30%;
3. Use doubles high-dynamic Proportional/Directional Valves to automatically adjust the oil flow and pressure
A. Buffer the hydraulic cylinder, to protect the cylinder from damage caused by inertia;
B. Guarantee production stability;
4. 360° Multi-Shaft Rotating and Compulsory Feeding:
A. Speedy and rotating feeding, with uniform mixing, to make sure that the density and intensity of the products are guaranteed
B. This uniform feeding is applicable for different kinds of raw materials and moulds;
5. Use heat treatment on moulds and main parts of the machines:
A. Heavy duty machine structure and wear resistant moulds;
B. The hardness reaches up to HRC 52-58;
C. Greatly improves the using lifetime of the machine by 50%.
We are professional clay brick making machine,used block machine and block pallet manufacturer, if you are interested, please come here.
