SMA female pcb mount connector
USD $0.3 - $0.5
/ Piece
2000 Pieces(Min.Order)
- 10000 Piece / Pieces per Month
- sz
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | ANNXIN | |
| Model Number | SMA-037 | Type | SMA | |
| Application | RF | Gender | Female |
Product Description
Specifications
SMA female pcb mount connectorRF coaxial connector
good lead time usually 7 work days
best after-sales service
SMA female pcb mount connector clip type
RF coaxial connector
Key spec.: S=6.5mm L=13.5mm screw length =4mm pcb layout gap should be 1.35mm
| ||||||
| Temperature range | -65~+165 | Insulation resistance | ≥5000MΩ | |||
| Characteristic impedance | 50Ω | Dielectric Withstanding voltage | 1000V(r ms) | |||
| Frequency range | With flexible cable | 0~12.4GHz | Contact resistance | Center conductor | ≤3mΩ | |
| With semi-rigid/flexible cable | 0~18GHz | Outer conductor | ≤2mΩ | |||
| VSWR | With flexible cable | ≤1.15+0.02F | Durability | 500 Cycles | ||
| With semi-rigid/flexible cable | ≤1.05+0.02F | |||||
| Material And Plating | ||||||
| Body | Brass , gold plated or stainless steel passivated | |||||
| Male center contacts | Brass , gold plated | |||||
| Female center contacts | Beryllium copper , gold plated | |||||
| Insulators | PTFE | |||||
| Gaskets | Silicon rubber | |||||
| Crimp ferrules | Copper alloy , gold or nickel plated | |||||
below are our new produtcs:
