SMA Female R/A Connector for PCB

Name: SMA Female R/A Connector for PCB
Brand: ANNXIN
SKU: 134364045

US$ 0.3 - 0.8 MOQ: 2000 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ANNXIN

Model Number:

SMA-021

Dongguan Annxin Electronics Company Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ANNXIN

Model Number SMA-021

Type SMA

Application RF

Gender Female

Specifications

SMA female R/A connector for PCB
high quality factory price RF coaxial connector
good lead time usually 7 work days

SMA female R/A connector for PCB

we can supply all kinds of RF coaxial connectors

liking SMA ,SMB,MMCX,MCX,BNC,TNC,UHF,HFL,IPEX and so on. we are of factory price .we welcome OEM /ODM clients.

key spec.: H=7.0mm L=17.0mm
Temperature range		-65~+165	Insulation resistance		≥5000MΩ
Characteristic impedance		50Ω	Dielectric Withstanding voltage		1000V(r ms)
Frequency range	With flexible cable	0~12.4GHz	Contact resistance	Center conductor	≤3mΩ
	With semi-rigid/flexible cable	0~18GHz		Outer conductor	≤2mΩ
VSWR	With flexible cable	≤1.15+0.02F	Durability		500 Cycles
	With semi-rigid/flexible cable	≤1.05+0.02F
Material And Plating
Body		Brass , gold plated or stainless steel passivated
Male center contacts		Brass , gold plated
Female center contacts		Beryllium copper , gold plated
Insulators		PTFE
Gaskets		Silicon rubber
Crimp ferrules		Copper alloy , gold or nickel plated
