High Performance Rain Gutter Downspout Roll Forming Machine Rain Pipe Making Machine

 Rain Gutter Downspout Roll Forming Machine

Profile Drawing

Main specifications

Main motor power: 7.5KW

Number of forming station: about 20

Forming speed of square downspout roll forming machine: 6-12m/min

Voltage:  380V,3 Phase 50HZ (or depend on customers requirement)

Machine dimensions : 12000mm*1100mm*1200mm

Machine wight: about 12Ton

Axis material : High grade 45#steel

Axis diameter: 75mm

Roller material: High grade 45#,polished and coated with 0.05mm Chrome Surface.

Machine frame material: A3 steel,thickness 18mm

Electrical Control : PLC Conyrol System with touch screen

The Chart of Process flow

Decoiler--Coil guiding and feeding--Roll forming machine with safty guard--Tighten device--Cut to length--Output table--Curving machine

Main Components

Applications

Rainwater downpipe, downspout, rainspout, water pipe, drainpipe

Our Company is major trapezoidal roof roll forming machine manufacture based in China. Our mainly products include double level roll forming machines, trapezoidal roof forming machines, steel pipe forming mill, slitting lines and cut to length lines, etc. They are widely used in process sheet metal and form roof panels, shingle nails, glazed tiles, purlins, deck, downpipe and more, or for metal roll forming in steel shelving systems and highway guardrail systems, and so on.
For more information on our metal forming machines, or other products, we welcome you to contact us.
