Hot Melt Adhesive Machine
- XIAMEN PORT CHINA
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | YONGTAI MACHINE | |
| Model Number | YT-SB202 |
Product Description
Specifications
1.safe,convient to work,improve the efficiency.2.Spot spraying, strip spraying, Mist spraying or scraper nozzle gluing
l FEATURES:
1.The melting tank. Applicator temperature is exactly controlled by electronic P.I.D numeric controller to avoid carbonization inside the tank.
2. 2-channel glue route. Small light,Multiple function.Apply to shoemaking,packing and electronic industry.
3. Open tank for easy hot melt compensation.
4. Individual tempterature controllers for tank/hose/nozzle.
5. Can choose the gear pump or piston pump.
6. Use high-density stainless steel filter device, the double period of filtering, effective filtering impurities, increase the service life of equipment.
l SPECIFICATION:
ITEM | UNIT | YT-SP202 | YT-DP201 | YT-QB202 | YT-QB201 |
Tank Capacity | KG | 3.0 | 3.0 | 5. 0 | 5.0 |
Max. malting rate | KGHOUR | 5.0 | 5.0 | 7.0 | 7.0 |
Max. Operation temp. | °C | 200 | 200 | 200 | 200 |
Melt Power | Watt | 2060 | 1600 | 2160 | 2160 |
Motor Power | Watt | 60 | 60 |
|
|
Air pressure | KGCM² | 4-6 | 4-6 | 4-6 | 4-6 |
Demension(L*W*H) | MM | 420*380*640 | 420*380*640 | 575*740*640 | 575*535*640 |
Weight | KG | 32 | 30 | 35 | 34 |
Max. Viscosity | Cps | 100,000 | 100,000 | 120,000 | 120,000 |
Gun Qty. |
| 2 | 1 | 2 | 1 |
Power Requirement | Single Phase (1Φ), 220 V | ||||
Pump Type |
| Gear pump | Gear pump | Piston pump | Piston pump |
