Specifications
1)Laser cutting and engraving machine for rubber plate/rubber sheet2)CO2 laser tube
3)Water cooling system
4)Low price
Laser cutting and engraving machine for rubber plate/rubber sheet
Introduction
Adopting international advanced DSP control technology, it is the pioneer of fast and continuous curve cutting function and shortest processing path optimization function, which greatly increases the working efficiency. It automatically equalizes the light diminishing during the whole operating to ensure the same cutting effect in different areas. High-speed cutting control software and buffer function in high-speed movement can largely improve the production efficiency.
The software provides direct output of original files. It completely fits the graph formats such as CAD, CAM of CAD, CorelDraw software to meet the needs of the end users practical design requirements. You can define the engraving or cutting sequences with the color management program.
Technical parameters
Machine model: |
XTL-1290 Laser Engraving Cutting Machine |
Laser type: |
Sealed CO2 laser tube, wavelength: 10.64μm |
Laser power: |
60W / 80W / 100W / 150W |
Cooling mode: |
Circulating water cooling |
Laser power control: |
0-100% software control |
Control system: |
DSP offline control system |
Max. engraving speed: |
60000mm/min |
Max cutting speed: |
50000mm/min |
Repetition accuracy: |
0.01mm |
Min. letter: |
Chinese: 1.5mm; English: 1mm |
Table size: |
1200 x 900mm |
Working voltage: |
110V/220V,50~60Hz |
Working conditions: |
temperature: 0-45°C, humidity: 5%-95% |
Control software language: |
English / Chinese |
File formats: |
*.plt,*.dst,*.dxf,*.bmp,*.dwg,*.ai,*las, *doc |
Applicable Materials
Materials can be engraved:
acrylic, wood, cloth, leather, MDF, bamboo, rubber, glass, crystal, granite, marble, tile, ceramic, paper, magic bean, painted metal, etc.
Materials can be cutted:
acrylic, wood, cloth, leather, MDF, plywood, bamboo, rubber, asbestos rubber, paper, PVC, foam, EVA, plastic, etc.
Sample Picture
Certifications:
Exhibitions:
About us:
Jinan XinTian Technology Co., Ltd was established in 2004, It is a professional manufacturer engaged in research,development, production and service of Diode pumped Laser marking machine, Fiber laser marking machine,CO2 laser marking machine,Pneumatic marking machine,Laser engraving machine,Laser welding machine, Laser cutting machine and Laser trimming machine.
