Help Center7" 1000 Nits Lcd Monitor
Negotiable
MOQ: 100 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Other, industrial environment
Screen Size:
Other, 7"
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Products Status
Stock
Application
Other, industrial environment
Screen Size
Other, 7"
Response Time
5ms
Brightness
Other, 1000cd/m2
Interface Type
D-Sub, DVB, DVI, HDMI, RS232C, S-Video, TV-out, YPBPR
Contrast Ratio
500:1
Resolution
Other, 800*480
Widescreen
Yes
Panel Type
TFT
Pixel Pitch
0.0635(H)*0.1905(V)
Brand Name
Anrecson
Model Number
LC-HMI0701E
Place of Origin
Guangdong, China
| Specification | |
| 7" Industrial Monitor( Embedded Mount) | |
| Mode Name | LC-HMI0701E |
| Screen Size | 7″ |
| Active Display Area (mm) | 154mm(W)×93mm(H) |
| Display Mode | 16:9 |
| LCD Type | TFT-LCD |
| Resolution | 800×480 |
| Display Color | 16.7M |
| Pixel Pitch(mm) | 0.0635(H)×0.1905(V) |
| Brightness(nits) | 1000cd/m2 |
| Contrast Ratio | 500:1 |
| Viewing Angle | 140(H) /120(V) |
| Response Time | 5ms |
| Backlight | LED backlights |
| Interface | D-Sub15 pin(VGA),HDMI |
| Optional interface | HDMI /BNC |
| Power | DC12V 2A 50HZ/60HZ |
| Power Consumption | =<25W (Max) |
| Plug & Play | DDC 1/2B |
| OSD Control | Auto adjust, Brightness, Contrast, Hori. / Vert. Position, Clock, phase, Color, Language.. |
| MENU | Chinese/English(other languages supported) |
| Mount Method | |
| Mounting | Embedded Mount |
| Optional Mounting Way | VESA 75mm/100mm |
| Certificate Approval | CE,RoHS,CCC,FCC,ISO9000(optional UL) |
| Warranty | 1.5 years |
| Application | |
| ATM/ Kiosk/Transportation/ Industrial Automation/Medical Treatment | |
