Transformer Vacuum Oil Purifier for 110KV to 500KV Transformer
- Chongqing port
- Money Gram
You May Like
Product Details
| Condition | New | Flow | 100L/M | |
| Working Pressure | depend on different model | Place of Origin | Chongqing, China | |
| Brand Name | junneng | Model Number | ZL-100 | |
| Usage | Insulation Oil | Voltage | 50HZ 380Vdepend on different model | |
| Power(W) | depend on different model | Dimension(L*W*H) | depend on different model | |
| Weight | weight will be changed with changing the technical specification | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
ZL series of high-efficient vacuum oil purifier is case-hardened product of electric power industry.
ZL series of high-efficient vacuum oil purifier
-Usage:
It is widely used in power plant, hydropower station, electric power company, metallurgy, petrifaction, railroad, etc. It can purify unqualified transformer oil, mutual-inductor oil, switch oil and capacitor oil, also rapidly dehydrate, degasify and purify oil. Meanwhile, it also has the function of drying electric machine and injecting oil to electric equipment.
---Characteristics:
A: Super dehydration and degasification system. We adopt large cubage to rapidly separate water and gas from oil.
B: Reliable heating system to ensure heating and stable oil temperature.
C: Precise filtration system adopts high-grade filtration materials which has advantages of good mechanical intensity, multi-level filtration, gradually intensive and high filtration precision system.
D: Advanced pressure protection device and infrared control system can avoid the influence of wrong operation.
E: Integration has chain security protection. It can automatically control the oil pressure and oil level.
F: This machine can be used with BZ series of transformer oil discoloring device together to add the function of acid-removing, discoloring, uncombined carbon removing, and reducing damage.
Technical Parameters:
Model | Unit | ZLA-20 | ZLA-30 | ZLA-50 | ZLA-70 | ZLA-100 | ZLA-150 | ZLA-200 |
| |
Rated flow | L/min | 20 | 30 | 50 | 70 | 100 | 150 | 200 |
| |
Vacuum Range | Mpa | -0.05~-0.099 |
| |||||||
Temperature Range | °C | 40~80 |
| |||||||
Oil pump pressure | Mpa | 0.05~0.3 |
| |||||||
Total Power | kw | 33 | 38 | 46 | 62 | 90 | 120 | 144 | ||
Power |
| 50HZ 380V |
| |||||||
Working Noise | db(A) | ≤65~85 |
| |||||||
Cleanliness | NAS1638 | ≤NAS 6 |
| |||||||
Breakdown Voltage | kv | ≥75 |
| |||||||
Water content in oil | PPM | ≤3 |
| |||||||
Gas content in oil | % | ≤0.05 |
| |||||||
Filter precision | µm | ≤3 |
| |||||||
Inlet (outlet) diameter |
| 25 | 25 | 32 | 32 | 42 | 50 | 60 |
| |
Dimension(mm)
| L | 1380 | 1480 | 1670 | 1820 | 2000 | 2100 | 2200 |
| |
W | 870 | 980 | 1100 | 1200 | 1300 | 1400 | 1600 |
| ||
H | 1000 | 1200 | 1500 | 1500 | 1600 | 1800 | 1800 |
| ||
This is our catalogue for you to choose:
RZL lubricating oil purifier
RZL-B series lubricating oil purifier ---especially for removing large amount of water in oil
ZLA two-stage Vacuum oil purifier series
ZL series of high-efficient vacuum oil purifier
TZL turbine oil purifier
ZLC two-stage Multi-Function Vacuum oil purifier series
KL phosphate Ester Fire-Resistant oil filter machine series
JL portable-type oil purifier
LY plate pressure oil filtering machine
ZSC waste engine oil purifier
JNC waste engine oil regeneration distillation apparatus
