Product Details
| Place of Origin | Zhejiang, China | Brand Name | huaheng | |
| Model Number | BFH219-2# |
Product Description
Specifications
1,Type: bag filter housing
2,No.: single bags.
3,material: CS, SUS 304 or 316L
4, TOP-IN OR SIDE IN
Bag filter is often characteristic of high flow rate and long service life. It consists of stainless steel housing, bag holder and filters.
The bag filter housing is made of SS304 or 316L. With different sizes, it is capable of holding 1 to 8 bags. The opening can be flange type or screw type.
Bags filter housing with capacities of up to 24 bags.
The cover flange adopt handwheel and swing bolts ,open and close easily ,fast bag changeouts.
| customized products are available | |
| body | stainless steel 304 |
| surface treatment | bead blasting |
| body size | L219mm, W219mm, H1145mm |
| filtration precision | 1-800 micron |
| filtration area | 0.46m² |
| flow rate | 30m³/h 132GPM |
| working temperature | 40°C 100°F |
| max pressure | 20bar 300psi |
| O-ring | Buna N |
| bag material | PE |
| inlet/outlet connections | FNPT |
| closure type | swing bolt |
