500L Conical Jacketed Fermenter
- Shanghai/Ningbo
- T/T
You May Like
-
7 Barrel Steam Heated 2 Vessel Beer Brewing Equipment
-
Steam Heated 2 Vessel Brewhouse With Combination Mash//Lauter Tun and Combination Kettle/Whirpool for Brewing All Types of Beer
-
5 Barrel 155 Gallon Fermenter
-
7 Barrel Conical Fermenter
-
10BBL Brite Beer Tank
-
10bbl_315gallon_1192L SUS304 Dimple Jacketed Brite Tank
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | Huaheng | Processing Types | Other, Beer | |
| Dimension(L*W*H) | 800*800 | Certification | CE | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Huaheng Industry’s Conical Jacketed Fermenter are available from 500L to 10000L. The conical fermentation tanks have a dish top with cylindrical body. The 60° conical bottom is ideal for fermenting and improving the quality of beer as well as breeding yeast. All tanks are food grade stainless steel 304 with a 3mm thickness for 3BBL-70BBL, while larger tanks have a 4mm thickness. The cooling system is a dimple jacket with insulated polyurethane fill. All tanks are designed for up to 14.7 PSI and tested at 30 PSI. The inside of the tanks are polished to Ra≤0.4μm and the outside is a brushed / mirrored finish. All tanks come standard with 25% head space on top of working volume. All Conical come standard with a Racking Arm. Special orders may be placed along with custom features to your specifications.
Working Volume | Dimension of Tank(D×H) mm | Total Height | Diameter of Inlet & Outlet | PU Insulation | Manway Size |
500 | Φ800×800 | 1750 | Φ38 | 50 | 440×320 |
1000 | Φ1000×1200 | 2200 | Φ38 | 50 | 440×320 |
1500 | Φ1100×1400 | 2500 | Φ38 | 50 | 550×430 |
2000 | Φ1200×1500 | 2700 | Φ38 | 50 | 550×430 |
3000 | Φ1400×1700 | 3150 | Φ51 | 50 | 550×430 |
4000 | Φ1500×2100 | 3450 | Φ51 | 50 | 550×430 |
5000 | Φ1600×2200 | 3590 | Φ51 | 50 | 550×430 |
6000 | Φ1700×2200 | 3650 | Φ51 | 50 | 550×430 |
8000 | Φ1800×2700 | 4350 | Φ51 | 50 | 550×430 |
10000 | Φ2000×2800 | 4450 | Φ51 | 50 | 550×430 |
• Full Name: Zhejiang Huaheng Industry Co., Ltd
• Founded: 1990
• Registered Offices: Fuyang, Hangzhou, P. R. China
• Main Business Activity: Design, Manufacturing of Stainless Steel Tanks for Food& Beverage, Brewery & Winery, Dairy Industry etc.
• Quality Managing System: ISO9001:2008
• Employees: about 145
• Production Area: 20.000 sqm
Tanks manufactured by our company are guaranteed to be free from defects in workmanship and materials, under normal use and service, for a period of twelve (12) months from the date of installation, or 18 months from the date of manufacture or whichever occurs first. In case of serious quality issues due to the responsibility of our factory within our warranty period, we will recall our tanks to our factory for repair!
