Specifications
Steel Marking Machine with CE1.IPG fiber laser source
2.Permanent marks
3.Germany Scan Lab Galvo head
4.England Q-switch
Steel Marking Machine with CE
Laser marking provides a permanent message on an in-process or finished components.
Our laser marking machines can engrave text, serial and part numbers, company logos, bar codes, or 2D codes on all plain, painted, powder coated, anodized, or plated metal surfaces, whether they are flat sheets, curved surfaces, or cylinders.
Laser marking also produces very high quality permanent mark on most plastic and metal materials. A character as small as 0.010 inch and as large as 12 inches can be laser etched with our laser markers.
Features
- High Speed precision FIBER laser marking machine
- Supreme precision engraving for ultra small characters
- Long lasting life time (100,000 hours) of the laser module. (IPG laser source)
- Wide range of frequency band width (2k-1,000khz)
- Germany Scan Lab Galvo head, England Q-switch
- Automatically generates serial numbers and dates
- Multifunctional marking software
- Easy to install and move
- Lowest maintenance cost and energy-consumption
Specifications
1. Imported fiber laser generator and high-speed galvanometer scanning system. Good beam quality, long working life (100,000 hours). Stable performance and maintenance-free.
2. With the features of High speed, high precision and high efficiency.
3. Precision, fine and permanent marks. Easy to use.
4. This model can achieve automatic arrangement and modification of text, logo, symbols ,images, graphics, bar code, two dimensional barcode, serial number automatically increasing, etc.
5. With a wide range of application.
[In appearance, there are integrated model and detached model for choice.]
Application
This model can permanently mark a wide range of materials such as ordinary metals and alloys (steel, stainless steel, iron, copper, brass, aluminum, magnesium, zinc, etc.), rare metals and alloys (gold, silver, titanium, etc.), metal oxides, plastic, ABS material (electrical appliances shell, daily necessities), ink (translucent keypads, printed products), epoxy resin (electronic components, packaging, insulation layer), electroplating materials, coating materials, spraying materials, serial numbers and barcode marking, electric parts, mobile phone keypad, cell phone covers, surgical instruments, hardware metals, watch covers, rubber, ceramic, etc.
Technical Parameter
Laser generator |
Fiber Laser |
Laser power |
10W / 20W |
Standard marking area |
70mm×70mm |
Optional marking area |
35mm×35mm, 110mm×110mm, 130mm×130mm, 175mm×175mm |
Working table |
Manuel up and down aluminium alloy working table |
Marking speed |
Adjustable |
Cooling system |
Air cooling |
Control system |
Digital offline control |
Galvo positioning accuracy |
±0.01mm |
Power supply |
AC220V ± 5% / 50/60Hz |
Format support |
AI, BMP, PLT, DXF, DST, etc. |
Optional |
Rotary device for cylinder marking |
