Home > Industrial Equipment & Components > Pump & Vacuum Equipment > Water Pump > Dredge Pump For Dredger

Dredge Pump For Dredger

Chongqing Perpetual Import And Export Co., Ltd.

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Standard or Nonstandard:

Standard

Application:

Maritime

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard or Nonstandard Standard

Application Maritime

Specifications

Dredge Pump For Dredger

Our dredge pump systems are always high efficient. Due to their excellent, stable suction performance, long wear life and a minimum of maintenance, the systems are able to handle bigger volumes in less time and at a lower cost. We also make them with the high quality material so they are seldom out of service.The pumps are optimized by CFD (computer fluid dynamics) to get the highest pump efficiency at maximum sphere clearances over a wide range. The pumps are also designed to get an even wear with minimal wear rates.

The main features are

• long working life in abrasive conditions

• wear-susceptible parts available in abrasion-resistant materials

• wear-susceptible parts can be simply replaced

• wide sphere passage between vanes to minimize blockages

• easy disassembly for inspection and repair

Here are the details

Product No.	Capacity	Head	Impeller Speed	Efficiency	Inlet Diameter	Outlet Diameter	NPSHr	Max Flowed Particle [mm]		Pump Weight
Product No.	[m³/hr]	[m]	[r/pm]	[%]	[mm]	[mm]	[m]	Five Pieces	Three Pieces	[T]
TUF080-SP101	700--1100	20--45	500--750	65--70	300	250	4	132	220	4.5
TUF080-SP102	900--1500	40--60	500--650	70--74	350	250	4	86	144	4.6
TUF080-SP103	1500--2200	30--65	400--550	74--78	450	300	4	144	241	8
TUF080-SP104	2000--3000	40--65	400--550	74--78	450	350	4	147	245	8.8
TUF080-SP105	3000--4000	35--67	350--500	76--80	600	450	4.5	125	254	12
TUF080-SP106	4000--5500	40--65	350--450	78--80	650	500	4.8	150	250	17
TUF080-SP107	5000--9000	55--80	320--400	81--85	650	600	6	160	220	35
TUF080-SP108	8000--12000	60--85	280--380	83--85	750	700	6	180	280	50
TUF080-SP109	10000--15000	50--70	260--360	79--80	850	800	6	200	300	58
TUF080-SP110	12000--19000	50--75	280--330	83--85	950	900	6	210	320	85
TUF080-SP111	16000--25000	23--76	180--290	85--87	1100	1000	6	230	350	126
All sizes are approximate, other sizes available on request.
