Specifications
marine vertical centrifugal pumpOur varies products are widely used in many types of vessels.
Marine Vertical Centrifugal Pump-CLH series
CLH series marine pumps are used at cabin bottom to cool water and fight fire. It is able to carry sea water , fresh water and other liquid medium under 80°C.
| Type | CLH |
| Q (m3/h) | 3.15 to 1300 |
| H (m) | 10.8 to 137 |
| n (r/min) | 1450,2900 |
| P (kw) | 0.46 to 212.5 |
| NPSH (m) | 3.5 to 6 |
Marine Vertical Centrifugal Pump-CLH/2 series
CLH/2 series marine vertical double-stage double outlet centrifugal pump is used to deliver fresh water and sea water, widely used for cooling, fire control, chamber loading and other general water drainage. It can be used as the alkali liquid pump and distilling pump in seawater desalination.
| Type | CLH2 |
| Q (m3/h) | 51 to 389 |
| H (m) | 30 to 82 |
| n (r/min) | 1450 |
| P (kw) | 15 to 75 |
| NPSH (m) | 3 to 4.8 |
Marine Vertical Centrifugal Pump-CLZ series
CLZ series marine vertical self-priming centrifugal pumps are used at cabin bottom to cool water and fight fire. It is able to carry sea water, fresh water and other non-eroding liquid under 70°C.
| Type | CLZ |
| Q (m3/h) | 5 to 670 |
| H (m) | 20 to 115 |
| n (r/min) | 1450,2900 |
| P (kw) | 2.5 to 62.5 |
| NPSH (m) | 3.5 to 5 |
Marine Vertical Centrifugal Pump-CLZ/2 series
CLZ/2 marine vertical self-absorption-type double-double outlet pump is applied to muti-tasks such as cooling, fire fighting, bigle and ballast. It can be used on all types of ships. It boasts the characteristic of small size, good self-absorption performance.
| Type | CLZ/2 |
| Q (m3/h) | 40 to 389 |
| H (m) | 15 to 86 |
| n (r/min) | 1450 |
| P (kw) | 15 to 75 |
| NPSH (m) | 3.5 to 5.4 |
Marine Vertical Centrifugal Pump-CL series
CL series marine pumps are used at cabin bottom to cool water and fight fire. It is able to carry sea water , fresh water and other liquid medium under 80°C.
| Type | CL |
| Q (m3/h) | 9 to 360 |
| H (m) | 18.5 to 49.5 |
| n (r/min) | 2950 |
| P (kw) | 2.56 to 31.45 |
| NPSH (m) | 4,4.5,5 |
Certificate:
Approved by ABS/LR/BV/NK/DNV/RINA/RS/IRS/CCS etc.
For more information, talk to us NOW.
