Specifications
Marine Sewage Pumpto suck out liquid such as oily water, bilge water, fresh water and sea water etc.
Sewage Pump-DZ series
DZ series pumps are horizontal single cylinder electric plunger pump, which can be used to suck out liquid such as oily water, bilge water, fresh water and sea water etc.without hard paticle or fiber impurities below 85°C.
| Type | DZ |
| Q (m3/h) | 100 to 5000 |
| Outlet Pressure (MPa) | 0.2,0.29 |
| [Hs] (m) | 6 |
| n (1/min) | 53 to 70 |
| stroke (mm) | 28 to 120 |
| Dia (mm) | 20 to 60 |
Sewage Pump-CZW series
The CZW series pumps are newly developed self-priming centrifugal pumps for clean water or chemicals. The pumps have compact structure, long life expectancy and high efficiency to operate smoothly and reliably.
| Type | CZW |
| Q (m3/h) | 5 to 350 |
| H (m) | 12 to 40 |
| n (r/min) | 2900 |
| P (kw) | 0.935 to 31.45 |
| NPSH (m) | 4.5 to 6 |
Sewage Pump-CGW series
CGW series marine sludge discharge pump is a motor driven vertical single channel impeller centrifugal drainage pump. This kind of pump are suitable for transferring sewage, industrial waste water, oily water, fresh water and sea water at a temperature below 85°C, containing solids with diameter up to 1/3 of the pump port, and fibers with a length up to five times of pump diameter. They are the best choice in conjuction with waste water treatment plants.
| Type | CGW |
| Q (m3/h) | 3 to 600 |
| H (m) | 6 to 60 |
| n (r/min) | 970,1450,2900 |
| P (kw) | 0.37 to 75 |
Sewage Pump-CF series
CF series marine crushing pump is driven by marine motor. This pump features in integration, cutting and non-clogging drain, able to cut the long fibers, paper belts and other foreign substances in the sewage into pieces before draining them out.
| Type | CF |
| Q (m3/h) | 5 to 60 |
| H (m) | 8 to 50 |
| n (r/min) | 2900 |
| NPSH (m) | 3.5 |
Sewage Pump-WYXH series
WYXH series marine sludge oil circulation pump is a motor-driven horizontal centrifugal sludge oil pump. It is suitable for delivering heavy oil and sludge oil with temperature up to 90°C. Excellent conjuction with imcinerator in water treatment plant.
| Type | WYXH |
| Q (m3/h) | 6 |
| Pressure (MPa) | 0.1,0.2 |
| Motor Power (KW) | 1.1,2.2 |
| Inlet Pipe Dia (mm) | 32,40 |
| Outlet Pipe Dia (mm) | 40,32 |
Certificate:
Approved by ABS/LR/BV/NK/DNV/RINA/RS/IRS/CCS etc.
For more information, talk to us NOW.
