Help CenterMarine CIS Series Horizontal Self-priming End-suction Centrifugal Water Pump
Related Products
-
Marine Self-priming Vortex PumpNegotiableMOQ: 1 Set -
Marine Single Cylinder Electric Plunger/ Self-priming Centrifugal Sawege PumpNegotiableMOQ: 1 Set
-
Marine Vertical Self-priming Centrifugal PumpNegotiableMOQ: 1 Set
-
S Type Single Stage Split Case Large Axial Flow Pump/ Marine PumpUS$ 1 - 1MOQ: 1 Set
-
Hot-selling Peripheral Vortex PumpNegotiableMOQ: 10 Sets
Specifications
1.Iveco Daily Water Pump 504087367.2.For IVECO DAILY M.Y. 2006 VGL-NR.
3.Develop new products as per sample/drawing.
Operation data
1.flow rate (Q) 3.2-550m3/h
2.Lift head (H) : 20-80m
3.Suction height: 5-6.5m
4.Rotatory speed:1450/2900r/min
5.Suction performance:1.2-3.4 min/5m
6.Shaft power:0.46-126kw
7.Motor power:0.75-132kw
Characteristics
1. it has a self-priming function, no need to install at the end of the pipeline valve, pump body before work
just to ensure there are quantitative reservoir fluid can be cited with a "one-draining, life-long self-priming" function. Therefore, not only simplifies the piping system, but also improved working conditions.
2. With compact structure, easy operation, smooth operation, easy maintenance, high efficiency, long life.
Application
1. applicable to urban environmental protection, construction, fire, chemical, pharmaceutical, dye, printing and dyeing,
brewing, electricity, electroplating, paper, petroleum, mining, equipment cooling, oil tanker offloading, etc..
2.apply to clean water, sea water, and with an acid or base chemical medium with a general liquid and mushy pulp
(medium viscosity of ≤ 100 PCT amber, containing solid content up to 30% below).
3. fitted with arm-type nozzle, but also the water will into the air after spraying powder into a small raindrops
are farms, nurseries, orchards, tea plantations of good equipment.
4. can be, and any model, specification supporting the use of filter press, filter the slurry machine with a filter press
to send the best kinds of auxiliary pumps.
Performance
Model |
Capacity |
Head |
Rotary Speed |
Motor Power |
Inlet |
Outlet |
(m³/h) |
(m) |
(r/min) |
(kw) |
(mm) |
(mm) |
|
25ZX3.2-20 |
3.2 |
20 |
2900 |
0.75 |
25 |
25 |
25ZX3.2-32 |
3.2 |
32 |
2900 |
1.1 |
25 |
25 |
40ZX6.3-20 |
6.3 |
20 |
2900 |
1.1 |
40 |
32 |
40ZX10-40 |
10 |
40 |
2900 |
4 |
50 |
40 |
50ZX15-12 |
15 |
12 |
2900 |
1.5 |
50 |
50 |
50ZX18-20 |
18 |
20 |
2900 |
2.2 |
50 |
50 |
50ZX12.5-32 |
12.5 |
32 |
2900 |
3 |
50 |
50 |
50ZX20-30 |
20 |
30 |
2900 |
4 |
50 |
50 |
|
Packing:
1) Our production base has the consummation product research and development ability, with advanced testing facilities, our products got good reputation of stable quality;
2) Long life span and reliable working performance;
3) Positive customer feedback from abroad and domestic market;
4) Experienced in the field of exporting auto spare parts, our professional staff can provide you all-around service;
5) Competitive and reasonable price;
6) Able to develop new products as per client's requirements - produce according to your specification with technical drawing;
7) All products have been inspected strictly by our quality controlling department before delivery . Every piece of our product can be traced back.
