CB3282-87 Marine Surface Friction Watertight Upper Rudder Carrier

CB3282-87 Marine Surface Friction Watertight Upper Rudder Carrier thumbnail-1
CB3282-87 Marine Surface Friction Watertight Upper Rudder Carrier photo-1
US$ 1 - 1 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
Perpetual
Model Number:
CB3282-87
Contact Supplier Request Quote Chat Now
Chongqing Perpetual Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Chongqing, China
Brand Name Perpetual
Model Number CB3282-87
Part Other, Bearing

Specifications

Our surface friction watertight upper rudder carrier is designed and manufactured in accordance with the standard of CB*3282-87

The Surface Friction Watertight Upper Rudder Carrier is one of the commonest upper rudder carriers used for different ships. The proper diameter of the rudder stock is from 200mm to 600mm.



CB3282-87 Marine Surface Friction Watertight Upper Rudder Carrier



 Technical parameters:







Dia. Of Rudder Stock D1 D2 D3 D8 Connecting Bolt A B C E H T3 Key Size
200 216 466 670 590 M30×12 330 80 90 450 20 30 45×25×80
220 236 550 790 700 M36×12 375 85 100 505 20 30 45×25×90
240 258 620 860 770 M36×12 430 90 100 560 20 30 45×25×90
260 278 680 920 830 M36×12 460 95 110 600 20 30 50×28×100
280 300 720 960 870 M36×12 515 90 110 665 20 40 60×32×100
300 320 750 1110 940 M42×12 545 95 120 705 20 40 60×32×110
320 342 780 1180 1010 M42×18 570 100 120 730 25 40 60×32×110
340 362 840 1240 1070 M42×18 630 105 130 800 25 40 60×32×120
360 384 900 1300 1130 M48×18 690 90 130 880 25 60 60×32×120
380 404 960 1360 1190 M48×18 755 95 140 955 25 60 60×32×130
400 426 960 1360 1190 M42×12 600 110 140 800 25 60 70×36×130
420 446 1020 1420 1250 M42×18 635 110 150 845 30 60 70×36×140
440 468 1080 1480 1310 M42×18 665 105 150 885 30 70 70×36×140
460 488 1140 1540 1370 M42×18 700 110 160 930 30 70 70×36×150
480 510 1210 1610 1440 M42×18 730 115 160 960 30 70 80×40×150
500 530 1270 1670 1500 M42×18 760 120 170 1000 30 70 80×40×160
600 690 1450 1950 1785 M64×28 890 140 200 1300 40 80 100×50×190



*Remark: This data sheet is just for reference. We can also manufacture the size according to the requirement or drawing of our client.
