Guide Bar 4 Rolls Plate Production Line
- 10 Set / Sets per Month
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Tian Yi | |
| Model Number | TY-CEB-22 |
Product Description
Specifications
1.washing treatment for double side plate2.surface treatment of drying or wet membrane
3. brush even
4.remove oxidation
Characteristics:
The line is used as washing treatment for double side plate, usually it is used for surface treatment of drying or wet membrane, also it can use as flux after de-lead or tin. Two upper and two lower roll make the brush even. Spray with acid before brush, which can remove the oxidation layer.
Process Flow:
Put the plate—acid washing—pump washing—urban water washing—rotate the 4 roll brush—pump washing—hi-pressure washing—urban water washing—absorb—blow—dry with hot air—discharge
Main Parameter:
1.Outline Dimension 8151mm*1600mm*2030mm
2.Work Dimension 200mm*200mm(Min)
3.Convey Speed 0.5-5m/min(speed adjust by frequency conversion)
4.Convey Width 640mm
5.Convey Height 900±250mm
6.Water flow volume 15-20L/min
7.Power 28Kw
