DIN-Connector RF Directional Coupler(800-2500MHz)

Name: DIN-Connector RF Directional Coupler(800-2500MHz)
Brand: Setsail
SKU: 132977867
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Anhui, China

Brand Name:

Setsail

Model Number:

YFTX-RC-0825-DINF

Hefei Setsail Telecom Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Ningbo/Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Anhui, China

Brand Name Setsail

Model Number YFTX-RC-0825-DINF

Specifications

1.Low Insertion loss for RF Directional coupler
2.RF Directional coupler good VSWR
3.OEM of RF Directional coupler is ok.

800-2500MHz 6/10/15/20/30/40dB DIN Connector RF Directional Coupler

Technical Specifications

800-2500MHz 6/10/15/20/30/40dB RF Cavity Directional Coupler

Model	YFTX-RC-0825-06	YFTX-RC-0825-10	YFTX-RC-0825-15	YFTX-RC-0825-20	YFTX-RC-0825-30	YFTX-RC-0825-40
Frequency(MHz)	800-2500
Product Name	800-2500MHz, 6/10/15/20/30/40dB RF Cavity Directional Coupler
Coupling(dB)	6±0.8	10±1.0	15±1.0	20±1.2	30±1.5	40±1.0
Insertion Loss(dB)	1.7	0.8	0.5	0.4	0.3	0.5
VSWR	1.25
Power Capacity(W)	500
Directivity(dB)	20
RF Connector	N-female or DIN-female
Impedance(ohm)	50
Relative Humidity	5%-95%
Color	Black-plated
Temperature(deg)	-35~+125
Application	Indoor
