5.0MP digital trinocular microscope euipped with microscope camera

Digital eyepiece

5.0 MP USB digital camera equipped with built-in relay lens

Active resolution of sensor

2592*1944

Sensitivity

1.4V/ lux-sec

Dynamic rage

70.1 dB

Frame rate

10fps@2592*1944

Total magnification (optical eyepiece loaded )

7X ~ 45X

Equivalent magnification of digital eyepiece

28X   (17” LCD screen display pixel size: 0.2625mm )

Total magnification (digital eyepiece loaded )

19.6X ~ 126X

Optical eyepiece

WF10X20mm

Viewing head

Trinocular hand, 45°inclined, 55-75mm interpupillary distance adjustment range

Objective

0.7X ~ 4.5X

Total optical magnification

7X ~ 45X

Working distance

100.0 mm

Optical viewing field

28.6mm (7X)

Micro ruler

0.1mm / 10 mm

Illumination

Reflected and transmitted LED illumination with adjustable brightness

Working stage (base)

Pillar LED base 285mm X 238mm

Focusing adjustment range

49mm ( pillar vertical size 240mm)

CD of software

Future Win Joe imaging software with movable reticle

Packing

Carton size:  43cm X 25cm X 38cm
