0.35MP portable mini video stereo microscope

Specifications

0.35MP Sensor
720*480 active pixels
Built-in achromatic relay lens
Stereo microscope
Video out put

♦Applications:

By connecting with TV set or monitor, you can view images of fine target on screen, and no squinting with one eye, just be enjoyable and to share with others. It’s an affordable imaging solution for microscopy in industry, education and hobby.



♦Functions:

1. To capture images for living show;

2.Automatic white balance and automatic exposure to match environmental illumination change;



♦Benefits:

1. Easy installation and convenient operation;

2, Built-in relay lens to widen field and to have image sharp and bright and to cut away the background noise

3. High sensitivity sensor to capture clear images of dark target;

4. To be suitable for outdoor usage.



♦Quality control:

CE issued by SGS laboratory Verification No. SHEMO0808001971T01C

FC issued by SGS laboratory Verification No.SHEMO081100389IT01C

ROHS issued by POCE laboratory, Verification No.POCE13072325TCR

Copyright software of Future Win Joe V1.0  Registration Code:2009SR035346

ISO9001-2008 issued by kaixin certification co., Ltd Verification No. 06913Q12896R0S



♦Main specifications:

Video eyepiece	0.35 MP video camera
Active resolution of sensor	NTSC:720*480
Frame rate	60fps@720*480
Sensitivity	11.5V/lux-sec
Dynamic rage	80 dB
Total magnification (optical eyepiece loaded )	60X
Optical eyepiece	10X
Viewing head	Monocular vertical tube
Objective lens	6X
Working distance	26.5mm
Viewing field	3.0mm
Micro ruler	0.1mm / 10 mm
Illumination	Electrical illumination (3V / 0.25A lamp )
Focusing range	-22mm ~ +22mm
Fine adjustment range	1.8mm~2.2mm
Packing	Carton size:25cm X 27.5cm X 42.5cm
