Home > Industrial Equipment & Components > Conveyor & Parts > Conveyor > SPN Semi Electric Stacker

SPN Semi Electric Stacker

Name: SPN Semi Electric Stacker
Brand: SINOLIFT
SKU: 132448715

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

SINOLIFT

Model Number:

SPN

Contact Supplier Request Quote Chat Now

Shanghai Sinolift Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name SINOLIFT

Model Number SPN

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Semi-Electric Stacker
1.Capacity: 1000-2000kg
2. Fork Min. Height: 85mm
3. Fork Max. Height: 1600-3500mm

SPN Semi-Electric Stacker

1)Features

- The product has passed the CE certification.

- It is a half electric forklift for load and unload and short-distance transportation

- The operation is very easy.

- It is reliable. There is no noise and pollution.

- The malfunction rate is low.

- There are complete specifications for forks to meet the different demands of the customers.

2)Specification Date

Model		SPN1016	SPN1025	SPN1030	SPN1033	SPN1035
Rated Capacity	Kg	1000	1000	1000	1000	1000
Fork Min Height	mm	85	85	85	85	85
Fork Max Height	mm	1600	2500	3000	3300	3500
Mast Min Height	mm	1980	1830	2080	2230	2330
Fork Size	mm	150/160x60	150/160x60	150/160x60	150/160x60	150/160x60
Fork Length	mm	900/1100	900/1100	900/1100	900/1100	900/1100
Fork Overall Width(adjustable/fix)	mm	330~640/550
Turning Radius	mm	1350	1350	1350	1350	1450
N.W	kg	396	443	466	495	500
Fork Wheel	mm	Φ74x70	Φ74x70	Φ74x70	Φ74x70	Φ74x70
Large Wheel	mm	Φ180x50	Φ180x50	Φ180x50	Φ180x50	Φ180x50
Accumulator (5hautonomy)	V/Ah	12/150	12/150	12/150	12/150	12/150
Lifting Motor Power (kw)	kw	1.5	1.5	1.5	1.5	1.5

Model		SPN1516	SPN1520	SPN1525	SPN1530	SPN1535
Capacity	kg	1500	1500	1500	1500	1500
Load Center	mm	400	400	400	400	400
Max Fork Height	mm	1600	2000	2500	3000	3500
Max Body Height	mm	2060	2560	3060	3560	4060
Fork Length	mm	1000	1000	1000	1000	1000
Fork Outer width	mm	300-680	300-680	300-680	300-680	300-600
Turning Radius	mm	1350	1350	1350	1450	1450
Wheel Base	mm	1185	1185	1185	1185	1185
Front Wheel Cardinal Distance	mm	316	316	316	316	316
Lifting Motor	V/kw	12/1.5-1.6	12/1.5-1.6	12/1.5-1.6	12/1.5-1.6	12/1.5-1.6
Battery	V/Ah	12/120-150	12/120-150	12/120-150	12/120-150	12/120-150
Charger	V/A	12/15	12/15	12/15	12/15	12/15
Overall Length	mm	1660	1660	1660	1660	1660
Overall Width	mm	810	810	810	930	930
Overall Height	mm	1330	1580	1830	2080	2330
Net Weight	kg	364	368	376	400	444

Model		SPN2016	SPN2020
Capacity	kg	2000	2000
Load Center	mm	400	400
Lifting Height	mm	1600	2000
Fork Length	mm	1000	1000
Fork width	mm	310~820	310~820
Turning Radius	mm	1350	1350
Lifting Motor	Kw	12/1.5~1.6	12/1.5~1.6
Battery	V/Ah	12/150	12/150
Charger	V/Ah	12.0/15	12.0/15
Overall Length	mm	1670	1670
Overall Width	mm	810	810
Overall Height	mm	1580	1580
Net Weight	kg	472	472

3)Photos

4)Workshop

5)Certificate

Shanghai Sinolift Equipment Co., Ltd is a production, design, manufacture, sales and service in one integrated production and trade enterprises. Main types of forklifts, material handling, storage and lifting products, also offer a variety of wire harnesses, TFT rule processing business, and produce a variety of OEM memory cards. Products are used in Germany and Japanese technology, all products passed "TUV", "CE", "GS" and "ISO9001" international quality system certification, the application of new technologies has unique.

6)Terms and Service

Lead time	3-4 weeks
Packing	Standard export fumigated wooden pallet, foam rubbers
Payment term	T/T payment in advance; L/C at sight
Lead term	FOB Shanghai or CFR/CIF
Warranty period	12 months
Shipping method	by sea or air; by express

7) Warranty Policy and Service Program

SINOLIFT give our customer warranty for each forklifts, pallet trucks (pallet jacks), stackers, table lifts , access work platform and drum handling equipments which remind us that we are always responsible for promotion our service.

Please check the warranty policy for the line of SINOLIFT material handling equipments from our sales department. Please note the warranty is for end user who purchase direct from SINOLIFT.

If your products from local distributor, please contact them. We provide full line after-sales service for our distributors. SINOLIFT believe local strategy is the best way for our distributors and local customers.

SINOLIFT offer all of handling equipments are reconditioned to our specifications, which come with a 12 months warranty on major components and 180 days on wearable items.
