Home > Instruments & Meters > Meter for Electricity > Current Meter > Panel Ampere Meter

Panel Ampere Meter

Name: Panel Ampere Meter
Brand: TAISUO; BKC; TST
SKU: 132386245
Availability: InStock

Zhejiang Taisuo Technology Co., Ltd.

US$ 21.98 - 29.98 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

TAISUO; BKC; TST

Model Number:

TS series

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo; Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name TAISUO; BKC; TST

Model Number TS series

Display Type Analog Only

Measuring Range 0.2mA

Accuracy Class ±0.5%F.S±2Digit

Supply Voltage 100Vac~240Vac

Operating Temperature 0-50℃

Dimensions 96*48

Specifications

1) Max. display 1999.
2) Measuring rate 2.5times/second.
3) Frequency range 40-200Hz (AC).

Specification:

1) Max. display 1999
2) Measuring rate 2.5times/second
3) Frequency range 40-200Hz (AC)
4) Power supply/consumption: AC 110/220V 50/60Hz/≤4.5VA
5) Voltage/insulation resistance: AC 1500V 1 min/DC 50≥100mΩ.

Technical parameter:

AC DIGITAL AMMETER
Model	Range	Resolution	PT.	Accuracy	Max. input
TSXXAA0.2	200mA	100uA	Direct input	±0.5%F.S±2Digit	500mA
TSXXAA2	2A	1mA	Direct input	±0.5%F.S±2Digit	5A
TSXXAA20	20A	10mA	20A:5A	±0.5%F.S±2Digit	1.2F.S
TSXXAA50	50A	100mA	50A:5A	±1%F.S±2Digit	1.2F.S
TSXXAA100	100A	100mA	100A:5A	±0.5%F.S±2Digit	1.2F.S
TSXXAA150	150A	100mA	150A:5A	±0.5%F.S±2Digit	1.2F.S
TSXXAA200	200VA	100mA	200A:5A	±0.5%F.S±2Digit	1.2F.S
TSXXAA500	500A	1A	500A:5A	±1%F.S±2Digit	1.2F.S
TSXXAA1000	1000A	1A	1000A:5A	±0.5%F.S±2Digit	1.2F.S
TSXXAA1500	1500A	1A	1500A:5A	±0.5%F.S±2Digit	1.2F.S
TSXXAA2000	2000A	1A	2000A:5A	±0.5%F.S±2Digit	1.2F.S

DC DIGITAL AMMETER
Model	Range	Resolution	Internal impedance	PT.	Accuracy	Max. input
TSXX-DA0.0002	200uA	100mA	1KΩ	Direct input	±0.5%F.S±2Digit	10mA
TSXX-DA0.002	2mA	1uA	100Ω	Direct input	±0.5%F.S±2Digit	100mA
TSXX-DA0.02	20mA	10uA	10Ω	Direct input	±0.5%F.S±2Digit	500mA
TSXXDA0.2	200mA	100uA	1Ω	Direct input	±0.5%F.S±2Digit	1A
TSXXAA2	2A	1mA	0.1Ω	Direct input	±0.5%F.S±2Digit	5A
TSXXAA20	20A	10mA	5MΩ	20A:75mV	±0.5%F.S±2Digit	1.5F.S
TSXXAA30	30A	100mA	5MΩ	30A:75mV	±1%F.S±2Digit	1.5F.S
TSXXAA50	50A	100mA	5MΩ	50A:75mV	±1%F.S±2Digit	1.5F.S
TSXXAA100	100A	100mA	5MΩ	100A:75mV	±0.5%F.S±2Digit	1.5F.S
TSXXAA150	150A	100mA	5MΩ	150A:75mV	±0.5%F.S±2Digit	1.5F.S
TSXXAA200	200VA	100mA	5MΩ	200A:75mV	±0.5%F.S±2Digit	1.5F.S
TSXXAA200	300A	1A	5MΩ	300A:75mV	±1%F.S±2Digit	1.5F.S
TSXXAA500	500A	1A	5MΩ	5000A:75mV	±1%F.S±2Digit	1.5F.S
TSXXAA1000	1000A	1A	5MΩ	1000A:75mV	±0.5%F.S±2Digit	1.5F.S
TSXXAA1500	1500A	1A	5MΩ	1500A:75mV	±0.5%F.S±2Digit	1.5F.S
TSXXAA2000	2000A	1A	5MΩ	2000A:75mV	±0.5%F.S±2Digit	1.5F.S
