ATI 7 SEGMENT SMALL LED DIGIT DISPLAY
Features—Our Products Stand out of Others
1.Over 12 years producing experience as the vendor of Samsung,Haier,LG etc.
2.Big scale of producing makes sure that your purchase cost is lower.
3.Advanced production line guarantees stable quality and long life span.
4.High luminous intensity output, low voltage and current operating, ultra-low power consumption.
5.Solid-state LED Epistar chip based, easy mounting on printed circuit board and sockets.
Product Exhibition—Show the Details for You
ELECTRICAL/OPTICAL CHARACTERISTICS AT Ta=25°C:
PARAMETER | SYMBOL | TEST CONDITION | Color | MIN | TYP | MAX | UNIT |
Forward Voltage ,Per Segment | VF | IF=20mA | white |
6
| 6.4 | 7 | V |
Reverse Current , Per Segment | IR | VR=5V | white |
|
| 50 | μA |
Peak Emission Wavelength | λp | IF=20mA | white | 460 | 462.5 | 465 | nm |
Luminous Intensity Per Segment | IV | IF=20mA | white | 70 | 80 | 100 | mcd |
Perfect Product Package—We Care about Your Goods and You
Our New Production Line—Make Your Choice to be The Best
Our Certifications—No Worry for Our Products
7 segment LED Display Series—More Choices for Your Purchase
