Product Details
| Place of Origin | Hunan, China | Brand Name | Huayuan | |
| Model Number | GH320240-5702 | Type | TAB |
in an anti-statics bag packed in carton or according to the customer's requirements
Product Description
GH320240-5702 LCD Display with RA8835
GH320240-5702 Display
Specification
Screen size | STN |
Display color | Display color:White Background color:Blue |
Type | STN |
Viewangle direction | 6’clock |
Driver mode | 1/240 DUTY 1/16 BIAS |
Backlight | LED |
Driver IC | IST3025T IST3026T or NT7701,NT7702 |
Data bus | 8080 interface and 8-bit |
Temperature range | Operation:-20 oC ---- +70oC Storage:-30 oC ---- +80oC |
Numbr of Dots | 320 x 240 |
Dot size | 0.33 x 0.33mm |
Dot pitch | 0.36 x 0.36mm |
Viewing size | 121 x 91.6mm |
Active area | 115.17 x 86.37mm |
Outline dimension | 165.55 x 109.0x 6.8mm Max. |
Drawing
Related Products
Character lcd module: 8x1, 8x2, 16x1, 16x2, 16x4, 20x2, 20x4, etc.
Graphic lcd module: 122x32, 128x64, 128x32,192x64, 24064, 240x128, 320x240, etc.
TFT lcd display: 1.44", 1.77", 2", 2.2", 2.4", 2.8", 3", 3.2", 3.5", 4", 4.3", 5",5.5", 5.7", 6.2", 7", 8", 9", 9.7", 10.1", 17",etc.
TN/STN/FSTN/HTN/VA segment customized lcd LED backlight panel
All kinds of LCD Module can customized.
