192X64 Dots Graphic Matrix LCD Display Module Blue Backlight for Arduino

192X64 Dots Graphic Matrix LCD Display Module Blue Backlight for Arduino thumbnail-1
192X64 Dots Graphic Matrix LCD Display Module Blue Backlight for Arduino photo-1
US$ 1 - 10 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
Huayuan
Model Number:
GH19264-3501
Contact Supplier Request Quote Chat Now
Shenzhen Huayuan Display Technique Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen airport
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hunan, China
Brand Name Huayuan
Model Number GH19264-3501
Type COB

Specifications

1.192X64 Dots Graphic Matrix LCD Display Module
2.Rohs and ISO 9001:2008 Certification
3.OEM.ODM can accept

Basic Parameter



192X64 Dots Graphic Matrix LCD Display Module



Model: GH19264-3501
Construction COB
Display Type STN,Negative or Positive ,Transmissive
Operating Voltage (VDD) 3.3V,5V
Backlight Voltage(VBL) 3.3V,5V
Operating Temperature (degree Celsius) -20 °c ~70 °c
Storage Temperature (degree Celsius) -30 °c ~80 °c
Viewing Direction 6:00
Dot Matrix 192*64
Viewing Area 84.00*31.00
Active Area 78.67*26.19
Outline Dimension 100.00*60.00*11.20
Controller KS0107 or equivalent controller
Backlight LED,Y-G,White



Outline Drawing







Interface definition describe




Number		 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

interface definition		 DB7 DB6 DB5 DB4 DB3 DB2 DB1 DB0 E R/W RS V0 VDD VSS CS2 CS1 RST# VEE A K







Product Range



1.  TN.STN.FSTN.TFT Panel/Module

2.  Customized LCD Panel/Module

3.  OEM.ODM are accept





Similar product



Part Number V.A Size(L*Wmm) Description Controller Outline Dimension
GH19264-3501 84.00*31.00mm STN/COB,LED,Y-G,WHITE/6:00/3.3V,5V KS0107 100.00*60.00*11.20mm
GH19264-3502 84.00*31.00mm STN/COB,LED,Y-G,WHITE/6:00/3.3V,5V KS0107 100.00*60.00*11.20mm
GH19264-3503 84.00*31.00mm STN/COB,LED,Y-G,WHITE/6:00/3.3V,5V KS0107 100.00*60.00*11.20mm
GH19264-4301 104.00*39.00mm STN/COB,LED,Y-G,WHITE/6:00/3.3V,5V KS0107 130.00*65.00*11.50mm
GH19264-4302 104.00*39.00mm STN/COB,LED,Y-G,WHITE/6:00/3.3V,5V NT7086 130.00*65.00*11.50mm
GH19264-4303 104.00*39.00mm STN/COB,LED,Y-G,WHITE/6:00/3.3V,5V KS0107 120.00*64.20*11.50mm
GH19264-4304 104.00*39.00mm STN/COB,LED,Y-G,WHITE/6:00/3.3V,5V KS0107 130.00*65.00*11.50mm
GH19264-4305 104.00*39.00mm STN/COB,LED,Y-G,WHITE/6:00/3.3V,5V KS0107 130.0*71.80*11.50mm
GH19264-4310 104.00*39.00mm STN/COB,LED,WHITE/6:00/3.3V,5V ST7920 130.0*71.80*11.50mm
GH19264-4312 95.00*38.00mm STN/COG,LED,WHITE/6:00/3.3V,5V ST7565R 127.30*61.60*10.50mm
GH19264-4313 104.00*39.00mm STN/COG,6:00/3.3V,5V UC1698U 108.00*51.00*8.20mm
GH19264-4314 85.00*32.00mm STN/COG,6:00/3.3V,5V ST7565P 97.50*46.00*8.20mm
