5-24V dc 510channel dmx to p9813 decoder
Introduction:
The DMX512 Data Decoder adopted the advanced decoding technology to convert the international standard DMX512/1990 signal into standard SPI (TTL) / LPD6803 / LPD8806 / TM1809/P9813/ TLS3001/WS2801 signals, each decoder has 96/510 DMX output channels, and the output channels can be expanded by adding decoders, therefore, most of LED lights can be controlled by DMX512/1990 protocol via the signal conversion, then widely used pixel light, digital tube light, floodlight, pixel screen, dancing floor light etc.
Product parameter:
Model |
BC-802-9813 |
Input Voltage |
DC5V-DC24V |
Input Signal |
DMX512/1990 |
Output Signal |
P9813 |
Decode Channel |
512 |
Control LED QTY |
170 |
Control Chip model |
P9813 |
DMX Socket |
Standard XLR-3 |
Size (mm) |
L125*W52*H40(mm) |
Weight |
315 g |
Feature function:
1.In put standard DMX512 protocol,Address can be set by DIP.
2.Automatically adapt input voltage DC12V-24V.
3.Self-Changing Mode exist.
4.Output TTL Signal.
5. Power loss memory function.
DMX512 Signal Decoder
1. Packaging:
After inspection the goods are packed in inner box and then carefully packed in cartons.
2. Shipping:
We will deliver goods by EMS/DHL/FEDEX/UPS and so on, it will takes around 5-7 working days to
arrived.
1. Our products meet international standards. OEM and ODM orders are welcome.
2. For first coopertion, welcome to buy sample to test quality, and we don't require MOQ for
sample, any quantity is available.
3. All products have 3 years warranty.
