300ma,700ma, 1050ma max 2700ma 1ch led amplifier
Introduction:
LED constant current power repeater is specially designed for our single color and RGB controllers to expand power output, it accepts PWM signal, double or three times more power can be reached by every one more power repeater, and in theory power repeater can be added unlimitedly. Also, the power repeater of constant voltage model and constant current model could be connected freely, suitable for synchronized controlling on different LED lamps.
Product parameter:
Model |
BC-991 |
Input power |
DC12V-48V |
Output signal |
Constant Current PWM |
Max load current |
350mA,700mA,1050mA…Max2700mA (As per customer request before shipping) |
Driving LEDs |
1-12pcs 1W(3W) LEDs |
Switch size |
L125xW45x H36(mm) |
Packing size |
L130×W47×H42(mm) |
Gross weight |
90g |
Product Dimension:
Ciruit diagram:
Feature function:
1.Automatically adapt to LED light which works from DC12V-48V.
2.Accept PWM control.
3.Constant current 350mA, 700mA, Maximum 2700mA (set before shipping.)
4.Unlimited connection quantity theoretically, unlimited power output expansion.
5.Maximum length from controller to repeater can be 500metersnotice.
6. Power loss memory function.
