Factory Swimming Pool and House Sand Filter,pond Sand Filter,swimming Pool Sand Filter,sand Filter for Water Treatment

Factory Swimming Pool and House Sand Filter,pond Sand Filter,swimming Pool Sand Filter,sand Filter for Water Treatment thumbnail-1
Factory Swimming Pool and House Sand Filter,pond Sand Filter,swimming Pool Sand Filter,sand Filter for Water Treatment photo-1
US$ 1 - 2,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
PIKES / EMAUX
Model Number:
V series
Contact Supplier Request Quote Chat Now
Guangzhou Vigor Health Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Huangpu
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name PIKES / EMAUX
Model Number V series

Specifications

factory swimming pool,pood and house sand filter
1.High quality & 1 year guarantee
2.UV resistance surface
3.Emaux Brand

Factory swimming pool and house sand filter,pond sand filter,swimming pool sand filter

1.Features:

*Made of fiberglass

*Top diffuser ensures even distribution of water over the top of the sand bed

*Large sand / water drain for rapid winterizing or serviciong

*Materials used are dependable, ono corrosive and are suitable fro all- weather performance

*Easy-to-use water drain plug and multi-port valve lets you select any of the valves/ filter operation with a simple lever-action

*UV resistance surface allows the filter to work under direct sunlight



2.Functions: Refer to 6- way Multi-port Valve

Maximum working pressure   250kPa/ 36psi/ 2.5bar

Factory testing pressure          400kPa/58psi/ 4.0bar

Size of silica sand                     0.5-0.8mm

Maximum filtration velocity       50m3/h/m2

Maximum water temperature  43 degree



3.Technical Characteristics:

Φ-350,   0.09 sq meter(filter area),   1.5’’/50mm(valve connections)   4.32 cbm/h(flow rate)   20kg(sand)

Φ-400,   0.13 sq meter(filter area),   1.5’’/50mm(valve connections)   6.48 cbm/h(flow rate)   35kg(sand)

Φ-450,   0.16 sq meter(filter area),   1.5’’/50mm(valve connections)   8.1 cbm/h(flow rate)   45kg(sand)

Φ-500,   0.22 sq meter(filter area),   1.5’’/50mm(valve connections)   11.1 cbm/h(flow rate)   85kg(sand)

Φ-650,   0.32 sq meter(filter area),   1.5’’/50mm(valve connections)   15.6 cbm/h(flow rate)   145kg(sand)

Φ-700,   0.40 sq meter(filter area),   1.5’’/50mm(valve connections)   19.5 cbm/h(flow rate)  210kg(sand)

...............

Φ-700(B),   0.41 sq meter(filter area),   2’’/63mm(valve connections)   20.2cbm/h(flow rate)  215kg(sand)

Φ-800,   0.50 sq meter(filter area),   2’’/63mm(valve connections)   24.9cbm/h(flow rate)  355kg(sand)

Φ-700,   0.64 sq meter(filter area),   2.0’’/63mm(valve connections)   31.2 cbm/h(flow rate)  470kg(sand)

Φ-1000,   0.40 sq meter(filter area),   2’’/63mm(valve connections)   39.0 cbm/h(flow rate)  620kg(sand)

Φ-1200,   0.40 sq meter(filter area),   2’’/63mm(valve connections)   51.6 cbm/h(flow rate)  860kg(sand)



4.Pictures:

   factory swimming pool and house sand filter,pond sand filter,swimming pool sand filter,sand filter for water treatment    factory swimming pool and house sand filter,pond sand filter,swimming pool sand filter,sand filter for water treatment    factory swimming pool and house sand filter,pond sand filter,swimming pool sand filter,sand filter for water treatmentfactory swimming pool and house sand filter,pond sand filter,swimming pool sand filter,sand filter for water treatment  factory swimming pool and house sand filter,pond sand filter,swimming pool sand filter,sand filter for water treatment

factory swimming pool and house sand filter,pond sand filter,swimming pool sand filter,sand filter for water treatment

factory swimming pool and house sand filter,pond sand filter,swimming pool sand filter,sand filter for water treatmentfactory swimming pool and house sand filter,pond sand filter,swimming pool sand filter,sand filter for water treatment







With us,your money in safe,with us,you business in safe,as quality is our culture.

Welcome to visit our showroom and factory!

Attn:Flora sales5&

Skype:flora2008miumiu

WhatsApp:+0086 13556025664

Mobile: +0086 13556025664
