Specifications
Factory Best Top mount and side mount swimming pool sand filter for irrigation1.Max pressure 40psi/2.8bar
2.Simple operate
Factory Best Top mount and side mount swimming pool sand filter for irrigation
side mount swimming pool sand filter tank
Description
MFS SERIES SIDE MOUNT SAND FILTER
Our innovative design and advanced technology offer superior filtration performance and clear water.
Mfs Series filters are blown at one-piece with high density polyethylene for its heavy duty performance and reliability.
Features:
- Suggested Installation: Domestic In-ground and above ground pool / hot spa tub
- Max operating pressure 40 psi / 2.8 bar
- Max temperature of 50oc (122 oF)
- Universal standard of union connection provided
- ABS lateral provided
- Suggested size of media : 0.5-0.8mm
Product Focus:
- Unique one-piece clamp with screw-type lock designed to simplify installation and allow tool-free servicing
- Equipped with multiport valve with 6-way functions
- Easy-to-read pressure gauge for easy inspection
Technical characteristics
Model No |
Filter Area(m ² ) |
Valve Connections |
Max Flow Rate |
Sand(kg) |
MFS17 |
0.14 |
1.5inch 55mm |
125 lpm 7.5m ³ /h |
40 |
MFS20 |
0.20 |
1.5inch 55mm |
175 lpm 10.5m ³ /h |
70 |
MFS24 |
0.28 |
1.5inch 55mm |
238 lpm 14.3m ³ /h |
125 |
MFS27A |
0.36 |
1.5inch 55mm |
325 lpm 19.5m ³ /h |
185 |
MFS27 |
0.36 |
2inch 63mm |
338 lpm 20.3m ³ /h |
185 |
MFS31A |
0.47 |
1.5inch 55mm |
373 lpm 22.4m ³ /h |
320 |
MFS31 |
0.47 |
2inch 63mm |
412 lpm 24.7m ³ /h |
320 |
MFS35 |
0.61 |
2inch 63mm |
515 lpm 30.9m ³ /h |
430 |
Detail Pictures:
Description
MFV SERIES TOP MOUNT SAND FILTER
Our innovative design and advanced technology offer superior filtration performance and clear water.
MFV Series filters are blown at one-piece with high density polyethylene for its heavy duty performance and reliability.
Features:
- Suggested Installation: Domestic In-ground and above ground pool / hot spa tub
- Max operating pressure 40 psi / 2.8 bar
- Max temperature of 50oc (122 oF)
- Universal standard of union connection provided
- ABS lateral provided
- Suggested size of media : 0.5-0.8mm
Product Focus:
- Unique one-piece clamp with screw-type lock designed to simplify installation and allow tool-free servicing.
- Equipped with multiport valve with 6-way functions
- Easy-to-read pressure gauge for easy inspection
Technical characteristics
Model No |
Filter Area(m ² ) |
Valve Connections |
Max Flow Rate |
Sand(kg) |
MFV17 |
0.14 |
1.5inch 55mm |
125 lpm 7.5m ³ /h |
40 |
MFV20 |
0.20 |
1.5inch 55mm |
175 lpm 10.5m ³ /h |
70 |
MFV24 |
0.28 |
1.5inch 55mm |
238 lpm 14.3m ³ /h |
125 |
MFV27A |
0.36 |
1.5inch 55mm |
325 lpm 19.5m ³ /h |
185 |
MFV27 |
0.36 |
2inch 63mm |
338 lpm 20.3m ³ /h |
185 |
MFV31A |
0.47 |
1.5inch 55mm |
373 lpm 22.4m ³ /h |
320 |
MFV31 |
0.47 |
2inch 63mm |
412 lpm 24.7m ³ /h |
320 |
MFV35 |
0.61 |
2inch 63mm |
515 lpm 30.9m ³ /h |
430 |
Detail Pictures:
Instruction of install our pool filter :
INSTALLATION
Installation had been made simple, the only tools
needed is a screw driver and pipe sealant for plastic.
Locate the Filter on hard, level surface, preferably in a
dry, shaded, and well-ventilated area.
1/ Place the empty tank in position.
2/ Fill the tank with
water to the level that covers the laterals
about 1/3 of the tank is recommended. This will avoid
damages to the laterals by the force of the
sand when pouring into the filter.
Manufacturing factory & Production Process of our sand filter
We have a experience and expertise together with our devoted staffs.
Our goal is " Quality is our culture and we will try best to provide the unsurpassed customer service"
Our company and office and join the exhibition
If you are interested our products,please feel free to contact Janet.
my skype is poolvigor.
