Specifications
governor:1.Type:microcomputer
2.Power Supply:AC,DC
3.Permanent Speed Droop:0~10%
4.Operation method:manuel&automatic
governor:
Hydraulic Governor
All kinds of auxiliary equipments can be provided, including inlet valve devices (large, middle and small size single spherical valve; butterfly valve and gate valve covering a specification from 200 to 3400mm, hand-electrically operated and hydraulic control), governors(large, middle and small size single microcomputer governor covering an operation oil pressure from 2.5 to 16MPa), excitation devices (large, middle size single SCR microcomputer excitation system and small size single microcomputer integrated panel) and automatic systems etc. High quality and competitive price can be promised.
This is technical parameters of programmable microcomputer governor.
Technical Parameter of Programmable Microcomputer Governor | |
Switching Time of Guide Vane Servomotor |
3~20 seconds |
Switching Time of Blade |
5~100 seconds |
Adjustable Range of Frequency |
45~55 seconds |
Adjustable Range of Power |
0~120% |
Proportional Coefficient (KP) |
0.5~20 |
Integral Coefficient (KI) |
0.05~10 |
Integral Coefficient (KD) |
0~5 |
Permanent State Slip Coefficient bp |
0~10% |
DI of Pressure Valve (mm) |
80, 100, 150, 200 |
Operating Oil Pressure (MPa) |
2.5, 4.0, 6.3 |
Static Fuel Consumption |
<1L/min |
Power Supply |
AC220V ± 15%, DC220V ± 10% |
Power Waste |
≤500w |
microcomputer governor
high oil pressure governor
