800KW~8000kw Twin Nozzles Pelton Turbine

Name: 800KW~8000kw Twin Nozzles Pelton Turbine
Brand: Hi-Sea
Availability: InStock

FOB Price

USD $10,000 - $100,000 / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port Chongqing
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Chongqing, China	Brand Name	Hi-Sea
Model Number	CJ
Electricity Generator Type	Hydro Power	Output Voltage (V)	6300

Product Description

Specifications

pelton turbine:
1.Power:800~8000kw
2.Water Head:150~600m
3.Runner Diameter:1.1m 1.25m
4.Frequency:50Hz 60Hz

pelton turbine:

water turbine

Pelton turbine (also called impulse turbine or action turbine) is the best choice for developing high water head with little flow water power resource. It has good characteristics like less investment, high efficiency, small size and compact structure. Pelton turbine units made by Hi-Sea Marine are suitable for 80~1000m water head with runner diameter 0.6~1.8m and capacity 100~18000kw. Both vertical and horizontal types can be provided, with single nozzle, twin or multi nozzles.

After several years' development, Hi-Sea has a professional sales team which can provide you the best service and meet your every requirement. High quality and competitive price can be promised.

This is technical parameters of 1600kw pelton turbine with twin nozzles and runner diameter 1.1m and 1.25m

Hydraulic Turbine						Turbine Generator			Valve
Runner Diameter(m)	Jet Diameter(m)	Design Head(m)	Design Flow(m3/s)	Output(KW)	Speed(r/min)	Power(KW)	Voltage(V)	Efficiency(%)	Model
1.1	0.09	250	0.80	1698	600	1600	6300	95	Φ500 Gate Valve
	0.11	190	1.10	1720	500	1600	6300	95	Φ600 Gate Valve
	0.125	160	1.25	1700	428	1600	6300	95	Φ700 Gate Valve
1.25	0.09	245	0.82	1730	500	1600	6300	95	Φ500 Gate Valve
	0.11	190	1.12	1775	428	1600	6300	95	Φ600 Gate Valve
	0.125	160	1.30	1720	428	1600	6300	95	Φ700 Gate Valve
	0.14	138	1.54	1758	375	1600	6300	94	Φ800 Gate Valve

1600kw pelton turbine with twin nozzles
