CE High quality low price spray booth GS-400
USD $9,000 - $13,000
/ Set
1 Set(Min.Order)
- 80 Set / Sets per Month
- Jiuzhou Port Zhuhai City China
- T/T
You May Like
- spray booth car painting for car body repair equipment VPB-E800
- Vico CE Approved Car Spray Booth Paint Booth Baking Booth #VPB-E800
- Vico Hot selling Car Spray Booth Factory Price Car Spray Paint Booth Automotive Paint Box #VPB-E700
- Vico hot sale CE Certificate auto electric spray booth car painting booth VPB-E600
- CE Approved Vico Auto Spray Booth Car Painting/Spray car painting booth on hot sale VPB-SD58
- CE Approved Auto Paint Room Automotive Vehicle Spray Booth Car Body Painting Machine VPB-SD68
Product Details
Power: | 25KW | External Size: | 7M*5.4M*3.75M | Internal Size: | 6.9M*3.9M*2.8M |
Voltage: | Do as customer required | Certification: | CE | Disc Dia.: | 6.9--3.9--2.7 |
No Load Speed: | 970/M | Place of Origin: | Guangdong, China | Brand Name: | G&P |
Model Number: | GS-400 |
Product Description
Introduction:
High quality and low price G&P spray booth/ paint booth/ spray room/ paint room/ baking booth/ baking room/ spray cabin.
CE.
GS-400 SPRAY BOOTH | ||
Room body | Dimension | Inside Dimension:L7000×W(4000+1525)×H3505(MM) Outside Dimension:L6900×W3900×H2700(MM) |
Wall Panels | Total thickness of EPS insulation (Expanded Polystyrene) and powder-painted steel plate wall is 50MM. Powder-painted steel plate is 0.426MM thick. | |
Basement and floor | Steel assemble, 5 rows of grilles with standing weight | |
Driving ramp | 2PCS diamond plate | |
Personal door | 1-fold with sight window, pressure lock, size: 800×2000(W×H) | |
Main door | 3-fold with sight windows, door without aluminum frame, size:3000×2700 (W×H) | |
Heating system | Frame | Sheet metal forming with powder spray process,inside galvanized board and fire-resistance material,outside white color plate |
Intake fan | 1SET 11KW professional turbo fan, air capacity:30000m³/h, Air speed:0.3~0.5M/S | |
Exhaust fan | 1SET 11KW professional turbo fan, air capacity:30000M³/H, Air speed:0.3~0.5M/S | |
Intake pipe | 4M straight pipe; 1PC 90° elbow;1PC 45° intake elbow; European flange | |
Exhaust pipe | 4M straight pipe; 1PC 90° elbow;1PC 45° intake elbow; European flange | |
Intake vent control damper | 1SET, manual VCD | |
Exhaust vent control damper | 1PCS, manual VCD 1SET, manual VCD | |
Smoke venting pipe | 4M straight pipe; 2PCS small elbow | |
Air damper | Cylinder and connecting rod driving system to transfer spray to baking paint freely | |
Burner | RIELLO/RG5S, Max Heating Productivity: 260000KCAL/H | |
Heat exchanger | Heat-resistant stainless steel heat exchanger, Maximum working temperature: 60~80℃ | |
Filter system | Ceiling filter | 6SETS filter; holding net installation model; Holder is made by section steel and with surface powder spray treatment. air filter efficiency:≥95% |
Floor filter | 5SETS, installed horizontally | |
Prefilter | 2SETS, M type filter structure, each set for intake and exhaust. | |
Lighting system | Ceiling light | 10UNITS×4PCS×40W=40PCS×40W, room illumination≥1100LUX |
Side light | 8UNITS×4PCS×40W=32PCS×40W, installed vertically | |
Control system | Electric cabinet | Main components imported are good quality; with overheat, overload, phase-absence protecting; motor starts in triangle model |
Differential pressure gauge | 1SET, finger model | |
Stop automatically | with timer to control heating time;System stops automatically | |
Constant temperature spraying | With constant temperature spraying paint function | |
Main power | 25.3KW, 3PH, 380V, 50Hz | |
E.P. Equipment | Environmental protecting filter | 7 layers drawer type active carbon filter |
