Home > Instruments & Meters > Electronic Instrument > Signal Generator > Digital Function Generators UTG9010C 10MHZ 20Vpp Signal Generator
Digital Function Generators UTG9010C 10MHZ 20Vpp Signal Generator
US$ 110 - 160
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UTG9010C
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Digital Function Generators UTG9005C 5MHz 1m- 20Vpp Signal GeneratorUS$ 90 - 120MOQ: 1 Piece -
NDT Instruments AR63A Handheld Digital Vibration Meter Gauge TesterUS$ 100 - 200MOQ: 1 Piece
-
ED-2000 Eddy Current Thickness Gauge MeterUS$ 250 - 450MOQ: 1 Piece
-
Electronic Phase Sequence and Motor Rotation Indicators UT261B Tester MeterUS$ 20 - 30MOQ: 5 Pieces
-
Electrostatic Field Meter SIMCO FMX-004 ESD Test Meters Electrostatic TesterNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UTG9010C
Digital Function Generators UTG9010C 10MHZ 20Vpp signal generator
Detailed
UT9000C series, can produce sine, square, triangle, pulse wave, sawtooth and other waveforms, wide frequency range up to 5MHz, having a DC level adjustment, adjust the duty cycle, VCF function, with TTL-level output, at the same time display the output signal, the amplitude and frequency can be used as a frequency counter external frequency measurement, the series has excellent frequency characteristics, square wave rising ≤50nS, all the electrical performance indicators have reached the level of similar foreign products
Contrast
| Features | Range | |||
| Model | UTG9002C | UTG9003C | UTG90005C | UTG9010C |
| Waveforms | Sine, Square, Triangle, Ramp, Pulse, TTL etc. | |||
| Amplitude | ||||
| Range (no load) | from 1mVpp to 20Vpp | from 1mVpp to 25Vpp | from 1mVpp to 20Vpp | from 1mVpp to 20Vpp |
| Accuracy | ±5% | |||
| Resolultion | 0.1mV | |||
| Frequency | ||||
| Range | from 0.2Hz to 2MHz | from 0.2Hz to 2MHz | from 0.5Hz to 5MHz | from 1Hz to 10MHz |
| Accuracy | ±1% | |||
| Resolultion | 1mHz | |||
| Output Power | 2Wp-p | 4.5W (Power output) | 2Wp-p | 2Wp-p |
| Output Impedance | 50Ω | 1Ω (Power output) | 50Ω | 50Ω |
| Attenuator | 20dB + 40dB | |||
| DC Offset | from -10V to +10V | |||
| Display | Frequency: 4-digits-LED, Amplitude: 3-digits-LED | |||
| Duty Cycle | from 10% to 90% | |||
| Distortion of Sine | ≤2% (at 1kHz) | |||
| Rise time of Square | ≤50ns | ≤50ns | ≤35ns | ≤35ns |
| VCF | ≥100:1 | No | ≥100:1 | ≥100:1 |
| Frequency Counter | ||||
| Frequency Range | from 0.2Hz to 10MHz | |||
| Amplitude Range | from 0.5Vp-p to 5Vp-p | |||
| Input Impedance | 10kΩ | |||
| General Characteristic | ||||
| Power | AC 220V,50Hz | |||
| Product Color | White and Gray | |||
| Product Net Weight | 2.5 Kg | |||
| Product Size | 320mm×240mm×100mm | |||
| Standard Accessories | BNC to Alligator Clips,Power Cord | |||
| Standard Individual Packing | Gift Box,English Manual | |||
| Standard Quantity Per Carton | 6 Pcs | |||
| Standard Carton Measurement | 660mm×410mm×600mm | |||
| Standard Carton Cross Weight | 18 Kg |
|||
Fitting
BNC to Alligator Clips;
Power Cord.
