Digital Function Generators UTG9005C 5MHz 1m- 20Vpp signal generator
Detailed
1, the whole machine adopts auto-calibration software, to ensure the high reliability of the instrument.
2, USES the direct digital synthesis (DDS) technology, has the same as the crystal oscillator frequency stability and very high frequency resolution.
3, with digital linear sweep, logarithmic sweep frequency and amplitude modulation function
4, sweep can be finished in the frequency range in the whole process of the instrument, without such as analog signal generator segments.
5, a large number of the integrated circuit, the realization of the complete chenghua, enhanced reliability.
6, the frequency parameter can be directly input and continuous adjustment, can also be a knob panel is concise and easy to use.
7, with a 100 MHZ frequency meter.
8, with output synchronization of TTL level output.
9, with output dc level adjustment and square wave duty ratio regulating function.
Contrast
| Features | Range | |||
| Model | UTG9002C | UTG9003C | UTG90005C | UTG9010C |
| Waveforms | Sine, Square, Triangle, Ramp, Pulse, TTL etc. | |||
| Amplitude | ||||
| Range (no load) | from 1mVpp to 20Vpp | from 1mVpp to 25Vpp | from 1mVpp to 20Vpp | from 1mVpp to 20Vpp |
| Accuracy | ±5% | |||
| Resolultion | 0.1mV | |||
| Frequency | ||||
| Range | from 0.2Hz to 2MHz | from 0.2Hz to 2MHz | from 0.5Hz to 5MHz | from 1Hz to 10MHz |
| Accuracy | ±1% | |||
| Resolultion | 1mHz | |||
| Output Power | 2Wp-p | 4.5W (Power output) | 2Wp-p | 2Wp-p |
| Output Impedance | 50Ω | 1Ω (Power output) | 50Ω | 50Ω |
| Attenuator | 20dB + 40dB | |||
| DC Offset | from -10V to +10V | |||
| Display | Frequency: 4-digits-LED, Amplitude: 3-digits-LED | |||
| Duty Cycle | from 10% to 90% | |||
| Distortion of Sine | ≤2% (at 1kHz) | |||
| Rise time of Square | ≤50ns | ≤50ns | ≤35ns | ≤35ns |
| VCF | ≥100:1 | No | ≥100:1 | ≥100:1 |
| Frequency Counter | ||||
| Frequency Range | from 0.2Hz to 10MHz | |||
| Amplitude Range | from 0.5Vp-p to 5Vp-p | |||
| Input Impedance | 10kΩ | |||
| General Characteristic | ||||
| Power | AC 220V,50Hz | |||
| Product Color | White and Gray | |||
| Product Net Weight | 2.5 Kg | |||
| Product Size | 320mm×240mm×100mm | |||
| Standard Accessories | BNC to Alligator Clips,Power Cord | |||
| Standard Individual Packing | Gift Box,English Manual | |||
| Standard Quantity Per Carton | 6 Pcs | |||
| Standard Carton Measurement | 660mm×410mm×600mm | |||
| Standard Carton Cross Weight | 18 Kg |
|||
Fitting
BNC to Alligator Clips;
Power Cord.
