ED-2000 Eddy Current Thickness Gauge Meter

ED-2000 Eddy Current Thickness Gauge Meter photo-1
ED-2000 Eddy Current Thickness Gauge Meter photo-2
ED-2000 Eddy Current Thickness Gauge Meter photo-3
ED-2000 Eddy Current Thickness Gauge Meter photo-4
ED-2000 Eddy Current Thickness Gauge Meter photo-5
ED-2000 Eddy Current Thickness Gauge Meter photo-6
US$ 250 - 450 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Graigar
Model Number:
ED-2000
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Graigar
Model Number ED-2000

ED-2000 Eddy Current Thickness Gauge Meter

ED-2000 Eddy Current Thickness Gauge Meter


DESCRIPTION

ED instrument is a portable,non-destructive,rapid and accurate measurement of coating thickness precision instruments.
Widely used in anti-corrosion, electroplating,chemical, automotive,shipbuilding,aviation,light industry,suitable for laboratory,factory and outdoor field use.This product complies with GB/T4957-2003 standards.
The magnetic thickness gage,according to magnetic induction principle,to detect the magnetic metal substrate without damage.( such as: iron , steel, and the hard magnetic alloy steel, etc.)
On the thickness of the non -magnetic coating (such as: zinc , aluminum, chromium, copper , paint, Lang , rubber, paint, etc. ) .
According to the vortex theory,vortex thickness gauge detect the non-magnetic metal without damage.
(such as:aluminum , copper, zinc , tin, etc. ) On thickness of the non-conductive coating ( such as paints, the anodic oxide film , ceramics, plastics, rubber, etc. ) .

FEATURES

  1.palm-sized and portable

  2.humanized design and simple operation.

  3.wide-angle liquid crustal display .

  4.buzzing alarm during operation.

  5.with automatic shutdown(can be set to 90 seconds,also can choose non automatic shutdown)

  6.for inches and centimeters converse.

  7.With power under-voltage tip.

  8.has statistic function:measuring times,average,standard deviations,maximum and minimum value.

  9."V "groove in front of the side head sleeve can ensure accurate measurement on the convex.


SPECIFICATION

Measuring range:



F type:0~3000μm


N type:0~2000μm


error: ±1μm or ±2~4%


The minimum radius of curvature: 5mm(convex);25mm(concave)


Minimum measuring area:φ20mm


Minimum substrate thickness:0.5mm(F);50μm(N)


Display:4 digi display,Optional backlit


Measuring unit:Um-mils optional


Calibration methods:standard,1point,2point


Power: 2AA batteries



PROBE

All probes are installed in the casing, in order to ensure safe and stable probe positioning and the probe is touch with pressure probe moderately. V -groove end of the pin can ensure accurate on the convex.
You must hold the tube on the probe when measuring,keeping the probe axis perpendicular to the test surface
Tip of the probe,which made of durable hard materials.











(Julie Zhou)
