Electronic Phase Sequence and Motor Rotation Indicators UT261B Tester Meter
Introduction
UT261 series of large-screen LCD display, UT261B AC voltage measure 90 - 600V600V, sustainable voltage test 30 minutes, the whole phase connection instructions, phase / out of phase indication, phase indicator determines that the motor connecting lines, UT261B unique non-contact motor steering instructions: no need to connect the line, just the instrument on the top of the motor and the motor in parallel (meter away from the motor is not more than 2.5cm), can withstand 2 meter drop test, test the line with a fuse option.
Application:
For three-phase system to determine the magnetic field direction, the phase sequence rotation, motor rotation direction and other measurements, is a durable, reliable, portable handheld regular installation, maintenance or repair of three-phase system or motor indispensable Measuring tools.
Specifications
| Specification | Range | |
| Model | UT261B | |
| AC Voltage (V) | 90V-600V | √ |
| Frequency Range (Hz) | 15Hz-400Hz | √ |
| Test Current (A) | < 3mA | √ |
| Features | ||
| Phase Sequence Indication | LED | |
| Missing Phase Indication | LED | |
| Motor Rotation Indication | LED | |
| General Characteristic | ||
| Power | 9V Battery (6F22) | √ |
| Product Color | Red and Gray | |
| Product Net Weight | 180g | |
| Product Size | 70mm X 75mm X 30mm | |
| Standard Accessories | Test Cord with Aligator Clip(×3),Crarrying Bag, Battery | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 40PCs | |
| Standard Carton Measurement | 645mm×450mm×340mm | |
| Standard Carton Cross Weight | 22.5Kg | |
Accessories
Test Cord with Aligator Clip(×3),
Crarrying Bag,
Battery (not included)
