High & Low Voltage Wire Tracker NF-820 Underground Cable Finder Anti-Interference Wire Tracker RJ45 RJ11 BNC Tester
Item Specifics:
Is_customized:Yes
Model Number:NF-820
Place of Origin:Shenzhen.China
Main function:Locate the wire towards with low voltage and high voltage
Other Function:The detection range is 0-3m deep and cable length 2000m for SCAN
Power Supply for receiver:9V Battery
Power Supply for main tester:3.7V lithium battery
Warranty:1 Year
1.Locate the wire towards which high or low voltage with alligator clip that can access AC220V high voltage without burning equipment .
2.No interference completely under any current or external environment when cable hunting.
3.The alligator clip and socket can be used at the same time.
4.The detection range is 0-2m deep and cable length 2000m for SCAN.
5.Amplifier probe signal has a light intensity and power light color to remind.
6.The target cable is under the floor slab, the ceiling or in the wall are not affected to be hunted.
7.The transmitting and receiving power can be adjust according to the actual situation.
8.The emitter with large capacity lithium battery, can be used rechargeable.
Function description:
* Locate the underground cable route and towards.
* Tone Generator signal strength can be adjusted from (0 ~ 3 m).
* Scan single cable, 2 core and multiple core wire.
* Low battery display.
* Polarity judgment.
* The emitter with charging mode.
Technical indexes:
| NF-820Transmitter specifications | |||
| Max. distance of transmission | ≥2000m | ||
| Max. working current | 40mA-50mmA±10% | ||
| Volume Regulate Function | Audio volume level control | ||
| Signal detect deep | 0-2m | ||
| Charge voltage | 800mA | ||
| Max. signal voltage | 8Vp-p | ||
| Voltage indicate | low 3.4v LED will flash | ||
| Battery Type | DC 3.7V | ||
| Dimensions (LxWxD) | 152 x 55 x 34mm | ||
| NF-820 Receiver specifications | |||
| Power supply | DC9.0V(NEDA 1604/6F22) x 1pc | ||
| Max. working current | 40mA-50mmA±10% | ||
| Voltage indicate | low 6v LED will flash | ||
| Work temperature | -10℃-+50℃ | ||
| Work humidity | 30%-60% | ||
| Dimensions (LxWxD) | 252x 45 x 28mm | ||
Accessories:
Tone Generator x 1pcs
Amplifier probe x 1pcs
9V battery x 1pcs
5V1A Charger x 1pcs
USB Charger cable x 1pcs
Earphone x 1pcs
Manual x 1pcs
Certificate of approval x 1pcs
Toolkit x 1pcs
Color box x 1pcs
Applied range
* The cable wiring, weak current system of integrated wiring circuit.
* Communication cabling, home decoration system.
* The telephone system, computer network and other metal conductor fields.
* Installation and maintenance of utility.
Standard carton:
Carton size : 55x35x50cm
Quantity: 30pcs/carton
Weight: 15.3KG
